22 DXZ768RMP
280-8334-00
English
CD/MP3/WMA Operations
Listening to a disc already loaded
in the unit
Press the [SRC] button to select the CD/MP3/
WMA mode.
When the unit enters the CD/MP3/WMA mode,
play starts automatically.
If there is no disc loaded, the indication “
NO
DISC”
appears in the display.
Pausing play
1. Press the [ ] button to pause play.
“PAUSE” appears in the display.
2. To resume CD play, press the [ ] button
again.
Displaying CD titles
This unit can display title data for CD-text/MP3/
WMA disc and user titles input with this unit.
1. Each time you press the [T] button, the title
changes in the following order:
●CD-TEXT disc
Artist name
CD-text title (track)
User title(disc)
(None)
User title(disc)
(None)
CD-text title (disc)
Artist name
CD-text title (track)
CD-text title (disc)
●MP3/WMA disc
Folder
Track
Track
Album TAG
Album TAG
Artist TAG
Artist TAG
Title TAG
Title TAG
Folder
Folder
Track
Note:
• If the CD playing is not a CD-text CD or no user
title has been input, “ ” appears in the display.
• If MP3/WMA disc is not input TAG, “
A
” appears in
the display.
• For MP3, supports ID3 Tags V2.3 / 2.2 / 1.1 / 1.0.
•Tag displays give priority to V2.3 / 2.2
• In the case of album Tags for WMA, the
information written into the extension header is
displayed.
• Only ASCII characters can be displayed in Tags.
Selecting a track
●Track-up
1. Press the [å, ∂] lever upward to move
to the beginning of the next track.
Note:
• When playing a CCCD (Copy Control CD), set the
setting to CD type. When this is set to MP3/WWA
type, the CD cannot be played normally in some
cases.
Loading a CD
1. Press the [Q] button. The SLOPING
CONSOLE opens.
2. Insert a CD into the center of the CD SLOT
with the label side facing up. The CD plays
automatically after loading.
Notes:
• Never insert foreign objects into the CD SLOT.
• If the CD does not insert easily, there may be another
CD in the mechanism or the unit may require service.
• Discs not bearing the or mark and
CD-ROMs cannot be played by this unit.
• Some CDs recorded in CD-R/CD-RW mode may
not be usable.
Loading 8 cm compact discs
∗ No adapter is required to play an 8 cm CD.
∗ Insert the 8 cm CD into the center of the insertion slot.
Backup Eject function
Pressing the [Q] button ejects the disc even if
the power to the unit was not turned on.
1. Press the [Q] button. Remove the disc after
it is ejected.
Note:
• Always close the sloping console after opening it
or ejecting the CD.
• Be careful not to catch your hand or
fingers while closing the SLOPING
CONSOLE.
• Do not try to put your hand or fingers in
the disc insertion slot. Also never insert
foreign objects into the slot.
• Do not insert discs where adhesive comes
out from cellophane tape or a rental CD
label, or discs with marks where
cellophane tape or rental CD labels were
removed. It may be impossible to extract
these discs from the unit and they may
cause the unit to break down.
CAUTION
