(31/104)
Item OP
code
page
OP code Parameter Remarks
AUDIO INPUT 02h 2Eh 0: No mean
1: IN1
2: IN2
4: HDMI
6: OPTION
7: DPORT
10(0Ah): HDMI2
AUDIO DELAY 10h CAh 0: No mean
1: OFF
2: ON
DELAY TIME 10h CBh 0: (small)
|
100(64h): (large)
RESET
(AUDIO)
02h CBh 0: No mean
4: Reset
Audio category
Momentary
SCHDU LE
OFF TIMER 02h 2Bh 0: Off
1: 1 hour
|
24(18h): 24 hours
1 hour/step
SCHEDULE
ENABLE 02h E5h 0: No mean
1: No.1 Enable
|
7: No.7 Enable
DISABLE 02h E6h 0: No mean
1: No.1 Disable
|
7: No.7 Disable
SCHEDULE SETTINGS Refer to chapter 10
DATE & TIME Refer to chapter 9
DAYLIGHT SAVING Refer to chapter 9 and 15
RESET
(SCHEDULE)
02h CBh 0: No mean
5: Reset
Schedule category
Momentary
PI P
KEEP PIP MODE 10h 82h 0: No mean
1: OFF
2: ON
PIP MODE 02h 72h 0: No mean
1: OFF
2: PIP
3: POP
(4: STILL)
5: PICTURE BY PICTURE
- ASPECT
6: PICTURE BY PICTURE
- Full
PIP SIZE 10h B9h 0(small)
|
80(large)
PIP POSITION
X 02h 74h 0: left
|
100(64h): right
Y 02h 75h 0: top
|
100(64h): bottom
ASPECT 10h 83h 0: No mean
1: NORMAL
2: FULL
3: WIDE
4: ZOOM
