Nec UM351Wi (Multi-Touch) [21/119] Sound mute on

©NEC Display Solutions, Ltd. 2014-2017 21

3.7 [ 022. SOUND MUTE ON ]

Turns the sound mute on.

 Information 

If any of the following operations is done, the sound mute is turned off.

・ Input terminal switch

・ Video signal switch

・ Sound volume adjustment

Command

02h 12h 00h 00h 00h 14h

Response

 When the command succeeds

22h 12h <ID1> <ID2> 00h <CKS>

 When the command fails

A2h 12h <ID1> <ID2> 02h <ERR1> <ERR2> <CKS>
