9. Apply grease to the right Crank Arm (13).

Identify the Right Roller Arm (7) and orient it as

Attach the Right Roller Arm (7) to the right Crank

Arm (13) with an M8 x 20mm Screw (61), an

Axle Cover (44), and an M8 Washer (63).

Attach the Left Roller Arm (8) in the same

10. Apply grease to axle on the Right Roller Arm (7).

Then, identify the Right Pedal Arm (9), orient

it as shown, and slide it onto the Right Roller

Attach the Right Pedal Arm (9) with an

M8 x 20mm Screw (61), an Axle Cover (44), and

an M8 Washer (63).

Attach the Left Pedal Arm (10) to the Left

Roller Arm (8) in the same way.
