CP6910-P24 Series

Impact Wrench 1"

Item Part No. Description Qty. Item Part No. Description Qty.

A 2050553993 HANDLE ASS'Y (Incl: Kit No. A1, A2, A3, A4) E 2050554073 CLUTCH KIT

1 8940162678 Inlet Bushing 1 96 Cage 1

32 2050559703

Housing Assembly (Incl: Item No. 9, 10, 26)

1 97 8940162187 Cam 1

Bushing-Throttle Valve

1 98 8940162188 Dog 1

10 Bushing - Trigger 1 104 2050553193 Bushing-Cage 1

Bushing - Reverse Valve

1 F 2050554083 ANVIL ASS'Y (Incl: Kit No. F1)

41 8940162680 Gasket-End Cover 1 105 Anvil 1

44 Screw 4 F1 2050554093

SOCKET RETAINER KIT

45 Screw 4 106 O-Ring 1

48 Lock Washer 8 107 Ring-Friction 1

118 O ring 1 G 2050554103 CLUTCH HOUSING KIT

A1 2050554003 THROTTLE VALVE KIT 44 Screw 4

Spring-Throttle Valve

1 46 Lock Washer 4

5 Valve-Throttle 1 113 Clutch Housing Ass'y (Incl: Item No. 114, 115) 1

7 O-ring 1 114

Bushing-Clutch Housing

Bushing-Throttle Valve

1 115 Oil seal 1

A2 2050554013 TRIGGER KIT 117 Screw 1

Plunger-Throttle Valve

1 118 O ring 1

14 Trigger 1 H 2050554113 SUPPORT HANDLE KIT

Screw-Trigger Retaining

1 150 Handle - Support Black Painted 1

17 Trigger Holder 1 152 Screw 4

Screw-Trigger Holder

2 153 Lock Washer 4

A3 2050554023 REVERSE VALVE KIT I 2050554123 SCREWS KIT

24 O-Ring 1 44 Screw 4

25 Valve-Reverse 1 45 Screw 4

27 Lever-Reverse 1 46 Lock Washer 8

28 Pin 1 152 Screw 4

50 Ball 1 153 Lock Washer 4

51 Spring 1 J 2050554133 SMALL PARTS KIT

A4 2050554033 EXHAUST KIT 15 Screw-Trigger Retaining 1

82 Screw 3 18 Screw-Trigger Holder 2

83 Washer 3 28 Pin 1

85 Deflector 1 50 Ball 1

B 2050554043 REAR COVER KIT 51 Spring 1

41 8940162680 Gasket-End Cover 1 57 Pin 1

42 End Cover 1 64 Pin 2

45 Screw 4 82 Screw 3

46 Lock Washer 4 83 Washer 3

C 2050554053 REAR ENDPLATE KIT OTHER PARTS AND SETS

54 8940162177 Bearing 1 60 8940162182 Liner 1

57 Pin 1 61 2050553153 Rotor 1

58 Plate - Rear End 1 62 8940162181 Blades (Set of 6) 1

64 Pin 1 119 2050554943 Protective cover 1

D 2050554063 FRONT ENDPLATE KIT - 8940166788 Suspension yoke 1

64 Pin 1 - CA155779 Warning label 1

65 Plate-Front End 1

66 Oil seal 1

67 8940162185 Bearing 1

68 O ring 1

2050529643 OPERATOR'S MANUAL

2050554213 CE DECLARATION OF CONFORMITY 2050560693 TUNE UP KIT

6159948710 SAFETY INSTRUCTIONS 7, 24, 41, 62, 66, 68, 106,107, 115, 118

Recommended accessories

Hose whip Hose kit (incl. EasyFlow coupling) Nipple FRL kit (incl. EasyFlow coupling)

BSP (EURO 7.6mm) 6158112640 6153980575 6158105920 6153980375

NPT CA049271 6153980615 6158105780 6153980405

NPT (Asia 7.5mm) CA049271 6153980665 6158106850 6153980435

Spare parts without part number are not sold separately. High wear parts are underlined. Contact us at www.cp.com 2050560683 Rev 01

04/2013
