CP7711/CP7721 Series

Model C

Impact Wrench

Index No.

Part No. Description Qty.

Index No.

Part No. Description Qty.

8950240538

Hammer Pin Kit (2) 1

K 8950212244 Inlet Kit

8950240539

Hammer Kit(2) 1 32 Regulator Knob 1

8940173222

Cam 1 33 Air Inlet 1

8940173223

Hammer Cage 1 34 Spring 1

8940173226

Rotor 1 35 Steel Ball 1

15 8950221519 Rotor Blade Set(5)

1 36 Valve Bushing 1

8940173228

Cylinder 1 37 O-Ring 1

A 8940173429 Housing Kit

38 O-Ring 2

1 Housing 1 40 O-Ring 1

22 Bushing 1 41 O-Ring 1

B 8950240535 Spacer Kit

42 Spring Pin 1

3 Washer 1 43 Screen 1

4 Bushing 1 44 Retaining Ring 1

C 8950000150 Bearing Kit L 8940173430 Backhead Kit

18 Ball Bearing 1 2 Backhead 1

19 Ball Bearing 1 21 Gasket 1

D1 8950240536 Anvil Kit 1/4"

23 Valve Stem 2

5A Anvil 1/4" 1 24 Spring 2

6A O-Ring 1 25 Pin 2

7A Anvil Collar 1/4" 1 26 O-Ring 2

D2 8950240537 Anvil Kit 3/8"

27 Throttle Valve 2

5 Anvil 3/8" 1 28 Spring 2

6 O-Ring 1 29 Screw 2

7 Anvil Collar 3/8" 1 30 Bushing 1

E1 8950251300 Anvil Collar Kit 1/4"

31 Screw 1

6A O-Ring 5 32 Regulator Knob 1

7A Anvil Collar 1/4" 5 33 Air Inlet 1

E2 8950251301 Anvil Collar Kit 3/8"

34 Spring 1

6 O-Ring 5 35 Steel Ball 1

7 Anvil Collar 3/8" 5 36 Valve Bushing 1

F 8950221518 End Plate Kit

37 O-Ring 1

13 End Plate 1 38 O-Ring 2

18 Ball Bearing 1 39 Spring Washer 2

G 8950221520 End Plate Kit

40 O-Ring 1

17 End Plate 1 41 O-Ring 1

19 Ball Bearing 1 42 Spring Pin 1

H 8950212245 Valve Kit

43 Screen 1

23 Valve Stem 2 44 Retaining Ring 1

24 Spring 2

SP 8950280069 Small Part Kit

25 Pin 2

include 20,29(2),30,31,34,35,39(2),42,43,44

26 O-Ring 2

TK 8940173515 Tune-up Kit

27 Throttle Valve 2

include 15,21,26(2),37,38(2),40,41

28 Spring 2

J 8950212246 Trigger Kit

12 Throttle Lever 1 6159948710 Safety instruction 1

30 Bushing 1 8940173260 Operator's manual 1

31 Screw 1 8950900061 Warning Label 1

Spare parts without part number are not sold separately - High wear parts underlined

06/2015

8940173262 rev. 1
