Dors 1020 [5/32] Specifications

TELEVISION MAGNIFIER DORS 1020

TROUBLESHOOTING

Problem Possible reason Troubleshooting

When working with

the magnifier

it is not possible

to switch on ultraviolet

illumination.

The magnifier was connected

to the already switched on detector

(DORS 1100 or DORS 1200)

and was not identified correctly.

Put the device in standby

mode and then turn it on

again.

There is no picture from

the external

television magnifier

or there is no changing

over to the corresponding

video input by pressing

the SELECT button

on the magnifier.

Probably the pin is not

completely inserted in V1 jack

of the DORS 1100 detector

or in V1/V2 jack

of the DORS 1200 detector.

Put the pin deep into the jack

till it stops.

SPECIFICATIONS

Power sourse 12 V

Dimensions:

Width 81 mm

Length 63 mm

Height 55 mm

Weight of the device (within): 0,15 kg

Input current (within): 350 мA

Operating temperature +10°С to +35°С

Relative humidity at +25°С 40 to 80%

Atmospheric pressure 84 to 107 kPa

(630 to 800 mmHg)

In order to improve the magnifier quality, specifications and models are subject to change without notice.
