CP3019-.. & CP3019-..ES series

Erickson and Cnomo versions Collet Grinder

Item Part No Description Qty

A 2050542053

AIR INLET KIT

1 - Adapter complete 1/4" 1

2 - Silencer 1

3 - O-Ring 1

B 2050542063 THROTTLE KIT

4 - Spring valve 1

5 - Tube inlet 1

6 - Throttle valve 1

7 - Seat valve 1

C 2050542073 LEVER KIT

8 - Throttle lever 1

9 - Pin 1

10 - Pin 1

D 2050542083 REAR PLATE KIT

14 - Ball bearing 1

15 - Rear end plate 1

E 2050542093 FRONT PLATE KIT

19 - Front end plate 1

21 - Ball bearing CP3019-.. 1

20 - Collar rotor 2

F 2050542103 MOTOR KIT

12 - O-Ring 1

D 2050542083 REAR PLATE KIT 1

E 2050542093 FRONT PLATE KIT 1

16 400.134 Cylinder 1

17 434.55 Blade 3

18 426.92 Rotor 1

H 2050542113 COLLET HOLDER KIT

25 - Chuck-collet 1

G 2050541693 COLLET CLAMP KIT 1

I 2050542123 COUPLING KIT CP3019-..ES

29 - Fork coupling CP3019-..ES 2

30 - Spacer CP3019-..ES 1

31 - Cross coupling CP3019-..ES 1

J 2050542143 FRONT CAP KIT

24 672.142 Front cap 1

28 225.46 Front cap protection 1

Item Part No Description Qty

K 2050542153 EXTENSION KIT

32 666.157 Sleeve spacer CP3019-..ES 1

33 758.114 Ball bearing CP3019-..ES 3

34 501.77 Spindle extension CP3019-..ES 1

35 566.459 Housing extension CP3019-..ES 1

L 2050542163 FLAT WRENCH KIT

53 6158010030

54 6158010320

11 2050542193 Motor housing Kit 1

13 457.25 Governor 25K 1

13 457.26 Governor 31K 1

13 457.27 Governor 40K 1

13 457.28 Governor 20K 1

13 6154570450 Governor 18K 1

26 225.45 Bit Holding Gap

27 607.143 Nut

51 6155260590 Resilient collet series 300. 1

55 6157040190 1/4" air hose nipple for 8mm ID hose 1

56 6158751060 Exhaust hose L=31" 1

100 6158726110 Warning instruction 1

22 523.20 Chuck Collet

23 672.138 Front Cap

50 6155260460 CNOMO Collet Ø6

TUNE UP KIT

8940174736 Including Part No. 2, 12, 17, 9, 10, 21, 33 1

2050541923 Operator's manual

6159948750 Safety instructions die-grinder

2050541103 EC declaration die-grinder
