CP3109-13A4, CP3109-13A4ES, CP3109-13AC

Angle grinder

Spare parts without part number are not sold separately

2/2

2050541133 rev. 2

Item Part No Description Qty

L 2050541333 ANGLE HEAD KIT CP3109-13AC

E 2050541313 Bevel gear kit 1

O 2050541413 Collet clamp kit 1

42 6155704290 Shield 1

43 595.230 Housing angle 1

49 -

Cap-angle housing CP3109-13A4 &

CP3109-13A4ES

53 2050541433 Spindle-collet CP3109-13AC 1

62 6155260590 Serie 300 resilient collet 1/4" 1

M 2050541633 EXTENSION KIT CP3109-13A4ES

37 - Ball bearing CP3109-13A4ES 1

38 - Shaft CP3109-13A4ES 1

39 - Housing CP3109-13A4ES 1

40 - Sleeve CP3109-13A4ES 1

26 - Ball bearing 1

N 2050541643 PLUG KIT CP3109-13AC, CP3109-13A4

27 - Spacer CP3109-13AC, CP3109-13A4 1

28 - Plug CP3109-13AC, CP3109-13A4 1

O 2050541413 COLLET CLAMP KIT

54 - Cap CP3109-13AC 1

55 - Nut CP3109-13AC 1

Item Part No Description Qty

15 6153962340 Motor housing 1

16 457.19 Governor 24K 1

33 645.132 Spacer CP3109-13A4ES 1

50 6155041600 Wheel guard 4" CP3109-13A4 , CP3109-13A4ES 1

51 6156065150 Flange CP3109-13A4 CP3109-13A4ES 1

52 6155020640 Flange CP3109-13A4 CP3109-13A4ES 1

56 6155031440 Rear Flange type 27 1

57 6158726840 Exhaust hose (L=60" - 1,5m) 1

58 6158734150 Hose clamp 1

59 6157040170 Air hose nipple 3/8" for 5/8" ID hose 1

60 6158010030 Flat wrench 7/16" 1

61 6158020080

20-3 mm Pin wrench

CP3109-13A4, CP3109-13A4ES

62 6155260590 Serie 300 resilient collet 1/4" 1

63 6158010320 Flat wrench CP3109-13AC 1

68 6159901490 Grease gun 0,8 oz. (24g) 1

100 6158726840 Warning guard label 1

101 6158726110 Warning instruction 1

102 6158726900 Warning wheel speed 1

TUNE UP KIT CP3109-13A4ES

2050541663 including Part No: 4, 17, 18, 19, 22, 26, 32, 37, 44, 47

TUNE UP KIT CP3109-13 AC/A4

2050541673 including Part No: 4, 17, 18, 19, 22, 26, 44, 47

2050541123 Operator’s manual

6159948750 Safety instructions die-ginder

6159948760 Safety instructions grinder

2050541103 EC declaration die-grinder

2050541213 EC declaration grinder
