2 / 3 05/2012

CP3650 Series

CP3650-120ACC

Die Grinders

6159948750 SAFETY INSTRUCTIONS DIE GRINDERS

2050556683

REV03

05/2012

2050556703 OPERATOR'S MANUAL

2050556543 CE DECLARATION DIE GRINDER

Index

No.

Part No. Description Qty.

A 2050556023 Silencer Kit

2 Silencer 1

3 O-Ring 1

4 Spring Cylindrical

5 Valve 1

B 6153967360 Bushing Complete

14 Bushing 1

15 O-Ring 1

16 Pin 1

17 O-Ring 1

C 2050556033 Valve Kit

8 Spring Conical 1

9 Ball 1

10 Valve seat 1

11 O-Ring 1

D 2050556043 Rear Endplate Kit

21 Bearing 1

22 Rear Endplate 1

E 2050556063 Blades Kit

24 Blade 4

F 2050556053 Front Endplate Kit

27 Front Endplate 1

28 Plate Spacer 1

29 O-Ring 1

30 Bearing 1

G 6153933320 Housing Complete Kit 12000RPM

32 Housing 1

33 Stopnger Complete 1

53 Greaser 1

31 Insulator 12000RPM 1

37 External cover 1

51 Left side brand name plate 1

52 Warning label 1

36 Cover 1

1 Adaptater 1

39 396.001 Grease Kit - 5g 1

H 399.480 Bevel Gear paired set

38 Bevel gear 1

39 396.001 Grease Kit - 5g 1

I 2050556083 Output Bearing Kit

40 Bearing 1

46 Nut 1

47 Deecotr 1

48 Bearing 1

Index

No.

Part No. Description Qty.

J 2050556073 Motor Bearing Kit 1

30 Bearing 1

21 Bearing 1

K 2050556013 Small parts kit 1

46 Nut 1

47 Deector 1

23 Pin 1

19 Pin 1

4 Spring Cylindrical 1

1 6153967390 Adapter 1

7 6156452290 Disc Spring 1

12 6155960040 Lever Bracket 1

18 6153967350 Safety lever 1

20 6154570490 Governor 19K 1

25 6154261200 Rotor 1

26 6154001480 Cylinder 1

43 501.94 Collet Holet 1

44 6156071440 Nut 1

45 6155260630

Serie 200 Resilent collet dia 1/4" (Ø5,55mm

to Ø6,35mm)

1

50 673.98 Plug 1

L 2050556003 Tune Up Kit

24 2050556063 Blade Kit 1

3 O-Ring 1

11 O-Ring 1

15 O-Ring 1

17 O-Ring 1

29 O-Ring 1
