CP3650 Series

CP3650-120AB & CP3650-075AB

Angle Sanders

10/2016

2050556123 Rev. : 10

Spare parts without part number are not sold separately - High wear parts underlined

Index

No.

Parts No.

Description Qty

1 6153967390 Adaptater 1

6 6154300330 Inlet 1

7 6156452290 Disc Spring 1

12 6155960040 Lever Bracket 1

18 6153967350 Safety lever 1

20 6154570490 Governor 19K (120AB) 1

20 6154570500 Governor 15K (075AB) 1

25 6154261200 Rotor 1

26 6154001480 Cylinder 1

41 6155011130 Shaft 5/8" 1

46 605.86 Nut 1

50 673.98 Plug 1

A 2050556023 Silencer Kit 1

2 Silencer 1

3 O-Ring 1

5 Valve 1

B 6153967360 Bushing Complete 1

14 Bushing 1

15 O-Ring 1

16 Pin 1

17 O-Ring 1

C 2050556033 Valve Kit 1

8 Spring Conical 1

9 Ball 1

10 Valve seat 1

11 O-Ring 1

D 2050556043 Rear Endplate Kit 1

21 Bearing 1

22 Rear Endplate 1

E 2050556063 Blades Kit 1

24 Blade 4

F 2050556053 Front Endplate Kit 1

27 Front Endplate 1

28 Plate Spacer 1

29 O-Ring 1

30 Bearing 1

G 6153933290 Housing Complete Kit 7500RPM 1

32 Housing 1

33 6153974060 Stopnger Complete 1

53 Greaser 1

31 Insulator 7500RPM 1

37 External cover 1

51 Left side brand name plate 1

52 6158727900 Warning label 1

36 Cover 1

1 Adaptater 1

39 396.001 Grease Kit - 5g 1

Index

No.

Parts No.

Description Qty

G 6153933320 Housing Complete Kit 12000RPM 1

32 Housing 1

33 Stopnger Complete 1

53 Greaser 1

31 Insulator 12000RPM 1

37 External cover 1

51 Left side brand name plate 1

52 Warning label 1

36 Cover 1

1 Adaptater 1

39 396.001 Grease Kit - 5g 1

H 399.480 Bevel Gear paired set (120AB) 1

38 Bevel gear 1

39 Grease Kit - 5g 1

H 6153971710 Bevel Gear paired set (075AB) 1

38 Bevel gear 1

39 Grease Kit - 5g 1

I 2050556083 Output Bearing Kit 1

40 Bearing 1

46 Nut 1

47 Deector 1

48 Bearing 1

J 2050556073 Motor Bearing Kit 1

30 Bearing 1

21 Bearing 1

K 2050556013 Small parts kit 1

46 Nut 1

47 Deector 1

23 Pin 1

19 Pin 1

4 Spring Cylindrical 1

L 2050556003 Tune Up Kit 1

2050556063 Blade Kit

3 O-ring 1

11 O-ring 1

15 O-ring 1

17 O-ring 1

29 O-ring 1

2050554963 Operator’s Manual

2050554993 EC Declaration Sander

6159948770 Safety Instuctions Sanders
