Clarion VRX578RUSB [10/68] Control

English

Owner’s manual

3. CONTROL

®Á ®

®È ®Í ®Î ®Ï ®Ì

3-1 Button Functions

① : To remove the DCP (Detachable Control Panel)

② : To eject the disc (press this button more than a second if the unit is in middle of turning

the power off)

③

[+ VOL -] : To increase/decrease the volume (in a range from 0min to 33max)

④

[SOUND] : To enter/exit the SOUND mode

■ 2-ZONE : To enter the 2-ZONE mode (press the [SOUND] button more than a second)

To exit the 2-ZONE mode (keep pressing this button again)

⑤

ADJ : To enter/exit the ADJUST mode changing the settings

⑥

[SOURCE] : To enter/exit the SOURCE mode

To change the operation mode when closing the LCP (such as TUNER mode)

■ POWER : To turn on the power (press the [SOURCE] button more than 2 seconds)

To turn off the power (press this button more than 2 seconds)

※ If you press this button more than 2 seconds during turning the power off, the power of the

unit will be turned on.

⑦

[OPEN] : To open/close the LCP

■ TILT : To adjust the angle for the LCP, press and hold the [OPEN] button more than a second.

The LCP is moved to forward or backward. (There are 5 adjustable angles available)
