Chicago Pneumatic EXAMAX-FF1 [6/6] Contact us at www cp com

PART N° PART N° DESCRIPTION Qty PART N° PART N° DESCRIPTION Qty

6153604840 21079 Gauge psi/Bar with certificate 1 6153605920

Foot Kit idem EXE/EXA max.

6153604920 10006 Press. Adjst Valve 1 20847 Rubber foot 4

6153604930 10009 Back Pressure 1 20439 Screw 4

6153604940 10010 Shut-off Valve 1 20594 washer 4

6153604950 10011 Shut-off Valve 1 21251 Screw 4

6153605020 10120 Base Dir Ctrl Valve 1 6153605970

Piston Service Kit

6153605120 10132 Piston 1 6153606980 10198 Ball bearing 2

6153605230 10193 Fitting 3 6153606990 10199 Ball bearing 1

6153605280 10239 Pipe 1 6153607000 10200 Ring 1

6153605310 20820 Filter RMSA 1 6153607010 10202 Seal 1

6153605610 10094 Safety valve 1 6153605940

Piston Top Screw Kit

6153605620 10095 Oil Filter 1 6153607020 10178 Spring ring 3

6153605630 10134 Valve Block 1 6153607030 10187 Screw 3

6153605780 20038 Gland 1 6153605930

Piston bottom screw kit

6153605790 20053 Oil drain screw 1 6153607040 10177 Screw 6

6153605800 20331 Oil sight glass 1 6153607050 10176 seal 6

6153606000 20589 Frame 1 6153605330

Check valve kit

6153606090 20015 Piston 1 6153606730 10181 Screw 3

6153606240 21123 Bolt 1 6153607310 20374 Check Valve 2

6153606250 20161 Tap Extension 1 6153608360

Gauge connector kit

6153606690 10067 Dir Ctrl Valve 2 10238 Fitting 1

6153606700 10086 Engine Valve 1 20540 fitting 1

6153606710 10123 Dir Ctrl Valve 1 20692 gauge connector 1

6153606720 10138 L-connector 2 6153605040

Ctrl Valve Service Kit

6153606730 10181 Screw 3 10235 O-ring 1

6153606740 10194 Pump Body 2 10236 O-ring 1

6153606750 10196 Screw 2 10237 Check valve 1

6153606760 20012 Piston 1 6153607580

Screw Kit FRL EXA max

6153606780 20037 Gland 1 6153607060 10215 Washer 2

6153606800 20062 T-Fitting 1 6153607070 20876 Screw 2

6153606810 20126 Double Nipple 2 6153607080 20878 Washer 2

6153606820 20160 Flex Pipe Wall 1 6153607090 20877 Nut 2

6153606830 20164 Brass Fitting 1 6153607590

Motor Kit Screw EXA max

6153606840 20684 Filter Silencer 1 6153607020 10178 Spring ring 3+4+1

6153606850 20756 Gegenmutter 1 6153607100 20446 Cylinder Head Screw 4

6153606860 20757 Fitting 1 6153607110 20444 Cylinder Head Screw 3

6153606870 20778 L-connector twin 1 6153607120 20591 Bolt 1

6153606880 20808 Remote Control black 1 6153607130 20879 Spacer 1

6153606890 20821 Oiler 1 6153607140 20881 Nut 1

6153606900 20825 Muffer 1/2" 1 6153607600

Pipe Kit

6153606910 20867 Pipe 1 6153606800 20062 T-Fitting 1

6153606920 20868 Pipe 1 6153606920 20868 Pipe 1

6153606930 20870 Pipe 1 6153607790 20869 Pipe 1

6153606940 20872 Housing 1 6153607610

Seal Kit

6153606950 20873 Pump shaft 1 6153607150 10210 seal 1

6153606960 20874 Pipe 1 6153607160 20777 seal 1

6153606970 20875 Fixing bracket 1

6153607210 10139 L-connector 1

6153607320 20871 Fitting 1

6153607700 21256 Oil container 1

6153607780 21132 Tap Extension 1

6153609180 10042 Air Motor 1

6159921260

6159921190

CA155779

Accessories

6153605340

6153605430

6153608955

4-Port Block

Operator's Manual

Safety Instructions

Warning Label

Gauge Mpa with Certificate

Assembly tool

6159921370 rev. 04

16/11/2017
