PART N°

Titan PN

DESCRIPTION Qty PART N°

Titan PN

DESCRIPTION Qty

6153607690

Foot kit

6153604840 21079 Gauge bar / psi with certificate 1

6153607380 20847 Rubber feet 4

6153604880 21246 Oil sight glass with thermometer 1

6153607390 21168 Threaded pin screw 4

6153604920 10006 Press. Adjst Valve 1

6153608360

Gauge Connector Kit

6153604930 10009 Back Pressure 1

10238 Fitting 1

6153604940 10010 Shut-off Valve 1

6153604790 20540 Fitting 1

6153604950 10011 Shut-off Valve 1

6153604800 20692 gauge connector 1

6153604970 10046 Bolt 1

6153607620

Screw Kit

6153604980 10048 Oil drain screw 1

6153607340 20914 Screw 1

6153605020 10120 Base Dir Ctrl Valve 1

6153607400 10211 Screw 8

6153605080 10082 Valve Block 1

20446 Cylinder Head Screw 4

6153605230 10193 Fitting 1

6153607020 10178 Spring ring 4

6153605280 10239 Pipe 2

6153607080 20878 Washer 4

6153605610 10094 Safety valve 1

6153607410 20912 Screw 4

6153605660 10168 Piston 1

6153607140 20881 Nut 2

6153605670 10169 Piston 1

6153607420 10222 Washer 2

6153606050 10170 Piston 1

6153607630

Seal Kit

6153606710 10123 Dir Ctrl Valve 1

6153607150 10210 Seal 1

6153606720 10138 L-connector 3

6153607430 10214 Seal 1

6153606730 10181 Screw 1

6153607440 10034 Container Seal 1

6153606740 10194 Pump Body 1

6153607640

Safety Valve Pipe Kit

6153606750 10196 Screw 1

6153606800 20062 T-Fitting 1

6153606790 20038 Gland 1

6153607450 20916 Pipe 1

6153606820 20160 Flex Pipe Wall 1

6153607460 20917 Pipe 1

6153606840 20684 Filter Silenver 1

6153607650

FRL Screw Kit

6153606880 20808 Remote Control black 1

6153607470 10218 Nut 2

6153606930 20870 Pipe 1

6153607480 20704 Disc Shape 2

6153607030 10187 Screw 1

6153607490 21167 Screw DIN 2

6153607170 10021 Air-Motor 1

6153607660

Piston Service Kit

6153607180 10027 FRL Complete Unit 1

6153607500 10183 Seal 1

6153607190 10083 Engine Valve 1

6153606980 10198 Ball bearing 1

6153607200 10137 Y-connector 1

6153606990 10199 Ball bearing 1

6153607210 10139 L-connector 1

6153607000 10200 Ring 1

6153607220 10164 Pump Body 1

6153607510 10205 Ball Bearing 1

6153607260 10195 Steel Ball 1

6153607520 10206 Ring 1

6153607270 10204 Pump Shaft 1

6153607670

Piston top screw Kit

6153607280 10244 Housing 1

6153607030 10187 Screw 3

6153607290 20033 Gland 1

6153607020 10178 Spring ring 3

6153607300 20061 Bulk Head 1

6153605330

Check valvle Kit

6153607310 20374 Check Valve 2

6153606730 10181 Screw 3

6153607320 20871 Fitting 1

6153607310 20374 Check Valve 2

6153607330 20913 Pipe 1

6153605930

Piston bottom screw Kit

6153607350 20915 Fixing bracket 1

6153607050 10176 Spring Ring 6

6153607360 10052 Container lid 1

6153607040 10177 Screw 6

6153607370 20065 Male EVGE Fitting 2

6153605040

Ctrl Valve Kit

6153607680 21255 Oil container 1

10235 O-ring 4

10236 O-ring 4

10237 Check valve 1

Accessories

6159921260

6153605340 Gauge Mpa With Certificate 6159921190

6153605430 20375

Assembly Tool

CA155779

Operator's Manual

Safety Instructions

Warning Label

Contact us at www.cp.com

6159921360 REV 02

11/2015

Hydraulic Pump

EXA-MINI-SF1
