Erlit ER 5709TP-C24 [3/17] Dear customers
![Erlit ER 5709TP-C24 [3/17] Dear customers](/views2/1388205/page3/bg3.png)
4 5
EN
The shower cabin is intended for hydrotherapeutic procedures.
The product has functions of manual shower, hydromassage and tropical shower, hydromassage sprayers,
electronic control panel with FM radio and Bluetooth, fan, lighting.
GENERAL INFORMATION
We thank you for purchasing the shower cabin of ERLIT trade mark and hope that it will come up to all of
your expectations.
The shower cabin can be used in apartments, houses or hotels – in all cases its installation will be simple and
safe, while using it will give you pleasure and benefi t your health.
Shower cabins of ERLIT trade mark combine all of the latest designs developed by our company, introduced
in order to give this product even higher quality and make it even more convenient in exploitation.
The product you have purchased is manufactured in compliance with modern European technical standards,
meets mandatory construction and sanitary standards.
All products of ERLIT trade mark are manufactured in compliance with requirements of the highest standards,
which defi ne all technical parameters of shower cabins for sale in the European Union countries.
Please, read this installation and operation manual carefully in order to ensure the safest and the most eff
ective installation, utilization and maintenance of the product.
Manufacturer reserves the right not to notify the end user about diff erences in structures between the
obsolete model and the new, improved version of the shower cabin; however, we are sure that this will not
hamper your utilization of the product.
Thank you for the purchase!
DEAR CUSTOMERS!
• This product is intended for domestic use in the premises.
• Packaging elements (plastic bags, metal clips) may be potentially dangerous for children, thus put them
away to the unreachable place immediately aſt er installing the cabin.
• It is necessary to check completeness and integrity of the product aſt er opening the package.
• Always take the plug out of the socket or turn the electricity off on your electric service panel before starting
any cabin maintenance operations.
• Water feeding regulator must be in the middle position in order to avoid temperature shock If you are using
a sauna mode, don’t use the shower or hydromassage.
• Cleaning of shower cabin must be conducted with a soſt cloth or a sponge using liquid detergents.
• Water feeding system must be equipped with fi lters.
• It is not recommended to wash pets without using a protection rug.
RECOMMENDATIONS TO THE CUSTOMER
TECHNICAL FEATURES
• Used voltage 220 ± 10%.
• Used water pressure 0.2-0.4 MPa, water discharge 8-12 l/min. Temperature of hot water fed onto the cabin
should not exceed 70°С. Installation of coarse water fi lters is required.
• Level of canalization draining from fl oor up to tray must be at least 70 mm.
• Maximum load to the tray 210 kg.
• Mounting dimensions of hot and cold water pipeline 1/2” (15 mm), drainhole diameter 1-1/2” (40 mm).
• Upon fi nishing to use the cabin it is necessary to put a switch to OFF position.
Upon fi nishing to use the cabin it is necessary to shut down feeding of cold and hot water in the cabin.
LIST OF PROHIBITED ACTIONS!
• Installing the cabin on the street
• Misusing the cabin
• Using the cabin in the state of alcohol and intoxicated
• Standing on the edge of the tray
• Using the cabin by the people who have fear of closed space
• Using the cabin by children and elderly people without supervision by relatives
• Clean the sower cabin using abrasive and agressive detergents.
TRANSPORTATION AND STORAGE
The cabins are transported in a covered vehicle.
If the cabin subject to installation is delivered from the cold premise to the warm one, it is necessary for
each part of it to match the environment temperature fi rst. Aſt er purchase the product has to be stored in
the package in order to be accepted for aſt ersales service, before installation and acceptance for warranty
service.
