An optional board can slide
into the slot on the back of
the monitor.
Touch Pen
directly on image
to display
data to PC
Print
Save
Import
Write or draw
document
with Sharp MFP
Scan
Onscreen
Touch Menu
Get the Most out of Your Face-to-Face Interactions
Plug into Convenience and Collaboration
Intuitive Touch Signage
Effective and Interactive Communications
The PN-40TC1 employs a full-flat design with 10-point multi-touch
functionality. It provides a smooth, quick response for writing and
touch gestures, while delivering full HD (1,920 × 1,080-pixel)
resolution. Sized at 40 inches, the PN-40TC1 is just right for small
meeting spaces.
40-Inch Full HD Touchscreen LCD
The PN-40TC1 can be installed in a landscape, portrait, or horizontal
(face-up) orientation. This flexibility means you can use it for a wide
variety of applications in business, educational, and public settings.
Note: An included desktop stand is provided for landscape set-up.
Versatile Orientation
This optional PN-ZB03W allows up to 10 devices—
including Mac
®
or Windows
®
computers, smartphones,
and tablets—to connect to the PN-40TC1 simultaneously
without any cable hassles. You can display the content of
one device on the whole screen, or you can display the
content from up to four devices in a 2 × 2 split screen.
Enabling such wireless collaboration is a great way to
enhance productivity in work or educational environments.
Wireless Board (PN-ZB03W)
The optional PN-ZB03H can receive HDMI
video/audio and control signals sent via a single LAN
cable*
1
from up to 100 metres away. It also allows
you to remotely operate a PC from a USB device
connected to the board*
2
.
*1 Category 6 or higher shielded cable (available commercially)
*2 Requires an HDBaseT 2.0-compatible transmitter (available
commercially). Not all USB devices are supported.
HDBaseT Receiver Board
(PN-ZB03H)
Original Sharp software lets you manipulate a variety of different files
on the screen without actually opening the respective applications.
The files* are displayed onscreen as “sheets,” which can be stored in
onscreen virtual “drawers.” This software brings convenience and
originality to business meetings, in-store installations, and more.
* Viewable files: Microsoft Office (Excel
®
, Word, PowerPoint), PDF, JPEG/PNG/BMP/TIFF,
and WMV/AVI/MP4/FLV.
Note: Access the downloader on the bundled CD-ROM to install the software. In the case of
a face-up installation, please consult with your local authorised Sharp dealer or
representative.
SHARP Touch Viewing Software
This software provides a wide range of signage support for content
creation, scheduling, distribution, and display management. Sharp
offers an array of solution packages to match a variety of signage
needs, from a single standalone display to a network of up to 1,000
monitors.
SHARP Digital Signage Software (option)
The easy-to-launch SHARP Pen Software user interface incorporates
a menu comprising smartly arranged icons that provide easy access
to pen settings and other useful functions. In overlay mode, you can
write onscreen annotations or graphics directly onto photos, videos,
PDFs, and common Microsoft
®
files. Text and graphics written on the
PN-40TC1 can be stored in USB memory* or sent directly via e-mail
to selected recipients. The software links smoothly with the
PowerPoint
®
application, enabling you to perform various control
operations during slideshow presentations. Support for a portrait
set-up—newly introduced with this model—gives you more flexibility
for use in conference rooms and classrooms.
* Saved as PDF, BMP, JPEG, PNG, or SWSX files.
User-Friendly SHARP Pen Software
Compatibility with Crestron Connected software enables you to
remotely control and manage each monitor via a LAN network.
Crestron Connected
™
This software supports multifaceted wireless communication.
Content on the PN-40TC1 screen, including handwritten notes, can
be shared simultaneously with up to 50 devices. Also, files can be
exchanged between devices connected to the PN-40TC1.
Note: Access the downloader on the bundled CD-ROM to install the software.
SHARP Display Connect
• Mount for web camera
• Bundled stand for desktop set-up (landscape orientation)
• 16-hour daily operation
Other Key Features
Scanned documents can be directly imported to SHARP Pen Software
from a compatible Sharp MFP. Onscreen image data, including
handwriting, can be sent to a PC for storage or to an MFP for printing.
MFP Connectivity
Maximise the Value of Small Meetings to Achieve a Big Change
Sharp’s BIG PAD series makes meetings and communications smoother and more productive. Reinforcing the line-up is the
40-inch PN-40TC1, which offers a fresh approach to boosting the dynamism of business and educational organisations. It’s
ideal for meetings of two to six people held in small spaces—the so-called “huddle spaces” where a high proportion of
meetings take place in the modern world. Making the most of huddle meetings can transform communications and
accelerate business to a whole new level.
There are times in every day when you need to have some quick face time with a few of your colleagues or clients. It could be for a
project update, a brainstorming session, or a business meeting. Every one of these impromptu gatherings can be transformed into a
genuinely productive and creative session. All it takes is a little help from the PN-40TC1.
As well as coming standard-equipped with a range of interface terminals such as HDMI
™
and DisplayPort
™
1.2, the PN-40TC1 includes an
expansion slot compatible with the Intel
®
Mini Open Pluggable Specification (Mini OPS). This slot supports the addition of an optional wireless or
HDBaseT
™
receiver board. By making more effective use of the PN-40TC1, you get greater convenience and an expanded range of functionality.
With its 10-point multi-touch functionality and high-sensitivity capacitive touch technology,
the PN-40TC1 shines in a variety of roles and locations. Whether installed face-up or in a
landscape or portrait orientation, it excels as an interactive information interface. Not only
is it a powerful meeting tool, it can also be used to engage and inform people in stores,
museums, showrooms, and public spaces. The PN-40TC1’s versatile touch signage
capabilities make it a true value-adder.
With the PN-40TC1, everyone can engage
meaningfully in such small-group meetings
by sharing onscreen information. Intuitive
touchscreen operation, whether with a finger
or pen, facilitates active collaborations and
a lively exchange of opinions. And with the
optional wireless board, you can also have
BYOD meetings. Speedy, productive
collaborations become a reality.
Huddle Spaces
Set up a PN-40TC1 in your company’s visitor meeting space to transform your
interactions with clients and other visitors. Touchscreen functionality helps to bring
greater focus and productivity to your interactions. And the PN-40TC1 never has to sit
idly by. When not being used in a meeting, it can be used as appealing touchscreen
signage displaying corporate ads, notices, and other information.
Meeting Booths
In both business and educational settings, the PN-40TC1 enhances collaborations and
group learning sessions. SHARP Pen Software works with the PN-40TC1 in both
landscape and portrait orientations. This expands the product’s range of usage to cover
a variety of settings. For example, the PN-40TC1 can work as a sophisticated bulletin
board or flip chart. You can import data to display, write on it freely by hand, and save
your handwritten notes digitally for later reuse.
Learning Areas
Responsive and Intuitive Operation
Thanks to Sharp’s original capacitive touch
technology, the PN-40TC1 offers extremely
precise and smooth operation. The bundled
2 mm-tip touch pen facilitates communication by
supporting smooth and accurate onscreen writing
of fine text and lines. An onscreen touch menu
lets you easily switch inputs, change between
touch and pen modes, and access other
frequently used functions. The screen surface
uses anti-glare glass, which resists fingerprints,
and also reduces glare and reflections.
Stand-Alone Version PN-SS01
Network Version PN-SS02
Pro Version PN-SS05
Pro Web Server Version PN-SW05
Viewer Version PN-SV01
