CLEANING AND MOUNTING OVEN DOOR

Reversely perform respectively what you did while opening door to

reinstall oven door back.

Figure 16

Figure 16.1 Figure 16.2 Figure 17.1 Figure 17.2

Figure 17

Open the door fully

by pulling the oven

door toward

yourself. Then

perform unlock

operation by

pulling the hinge

lock upwards with

the aid of

screwdriver as

indicated in

Figure 16.1.

Set the hinge lock

to the widest angle

as in Figure 16.2.

Adjust both hinges

connecting oven

door to the oven to

the same position.

Later, close the

opened oven door

so that it will be

in a position to

contact with

hinge lock as in

Figure 17.1.

For easier removal

of oven door, when

it comes close to

closed position,

hold the cover

with two hands as

in Figure 17.2

and pull upwards.
