English
11
XMD3
Basic Operations
Adjusting the subwoofer
When you default select one of mode (LPF50, LPF80, LPF120)
∗ The factory default setting is “S-VOL 0”. (Adjustment range: -6 to +6)
1. Press the [ A-M ] button and select “S-VOL 0”.
2. Press the [ w ] or [ z ] button increases or deceases the
subwoofer volume.
Press and hold the [ w ] or [ z ] button automatically in-
creases or deceases the subwoofer volume.
3. When the adjustment is complete, press the [ A-M ] button
several times until the function mode is reached.
Adjusting the bass (Gain, Frequency, Q-curve)
This adjustment can be performed when the Z-Enhancer Plus is
set to “CUSTOM”.
1. Press the [ A-M ] button and select “BASS”.
2. Press the [ w ] button emphasizes the bass.
Press the [ z ] button attenuates the bass.
∗ The factory default setting is “B<G 0>”. (Adjustment range: –6 to
+6)
3. Press the [ d ] or [ a ] button to select “B<F 60>”.
Press the [ w ] or [ z ] button to select the frequency.
∗ The factory default setting is “B<F 60>”.(Adjustment 60/100/200
Hz)
4. Press the [ d ] or [ a ] button to select “B<Q 1>”.
Press the [ w ] or [ z ] button to select the Q-curve.
∗ The factory default setting is “B<Q 1>”.(Adjustment 1/1.25/1.5/2)
5. When the adjustment is complete, press the [ A-M ] button
several times until the function mode is reached.
Adjusting the treble (Gain, Frequency)
This adjustment can be performed when the Z-Enhancer Plus is
set to “CUSTOM”.
1. Press the [ A-M ] button and select “TREBLE”.
2. Press the [ w ] button emphasizes the treble.
Press the [ z ] button attenuates the treble.
∗ The factory default setting is “T<G 0>”. (Adjustment range: –6 to
+6)
3. Press the [ d ] or [ a ] button to select “T<F 10>”.
Press the [ w ] or [ z ] button to select the frequency.
∗ The factory default setting is “T<F 10>”.(Adjustment 10 kHz/15
kHz)
4. When the adjustment is complete, press the [ A-M ] button
several times until the function mode is reached.
Adjusting the balance
1. Press the [ A-M ] button and select “BAL 0”.
2. Press the [ w ] button emphasizes the sound from the right
speaker, press the [ z ] button emphasizes the sound from the
left speaker.
∗ The factory default setting is “BAL 0”. (Adjustment range: L13 to
R13)
3. When the adjustment is complete, press the [ A-M ] button
several times until the function mode is reached.
Adjusting the fader
1. Press the [ A-M ] button and select “FAD 0”.
2. Press the [ w ] button emphasizes the sound from the front
speaker, press the [ z ] button emphasizes the sound from the
rear speaker.
∗ The factory default setting is “FAD 0”. (Adjustment range: F12 to
R12)
3. When the adjustment is complete, press the [ A-M ] button
several times until the function mode is reached.
Adjusting the Z-Enhancer Plus
1. Press the [ Z+ ] button and select the Z-Enhancer Plus mode to
adjust.
2. Press the [ A-M ] button and press the [ w ] button adjusts in
the + direction; press the [ z ] button adjusts in the - direction.
● When “B-BST 0” is selected, you can adjust the bass in the
range of -3 to 3.
● When “IMPACT 0” is selected, you can adjust the bass and
treble in the range of -3 to 3.
● When “EXCITE 0” is selected, you can adjust the bass and
treble in the range of -3 to 3.
∗ Press and hold the [ Z+ ] button for 2 seconds or longer to change
to the “CUSTOM” mode.
Bass/treble characteristics become flat and the indication
“Z+FLAT” is shown in the display.
Press the [ Z+ ] button again to change to the “Z+ OFF” mode.
Turning on/off MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust the low sound area
like the normal sound adjustment function, but emphasizes the
deep bass sound area to provide you with a dynamic sound.
∗ The factory default setting is off.
1. Press and hold the [ A-M ] button for 1 second or longer to turn
on the MAGNA BASS EXTEND effect. “M-B EX” lights in the
display.
2. Press and hold the [ A-M ] button for 1 second or longer to turn
off the MAGNA BASS EXTEND effect. “M-B EX” goes off from
the display.
