MEASUREMENT FOUNDATION

IronWeld 160/180/200/220

WARNING: Indicator of thermoprotection will light after long period of operation. That means that inner tem-

perature exceeds permitted value. In that case stop work and let the instrument cool down. You can continue

operation when the indicator is switched off.

Installing of welder

Do not expose your welder to rain or direct sunlight. You must provide good ventilation. The distunce above

welder must be no less than 50 cm. In case of poor inner ventilation, set the equipment to get rid of smoke

and protect from wind.

Connection of power suply

Connect electric cable to single-phase net of power supply 220V with switch.

It’s forbidden to use voltage 380V. As it can damage the tool and operator.

When connecting welder to the electric network under voltage 220V and with frequency 50 Hz, it’s necessary

to provide protection of the socket. It’s important for connection with automatic switch or 25 A fuse.

WARNING: Use socket with ground connection to connect the tool.

Connection of cables with electrode holders and earth clamp

Connection of welding cable. Connect bayonet plug of welding cable to the output connection on the front

panel with marking «+» and turn clockwise.

Electrode holder is used for electrode clamp

Connection of earth cable. Connect bayonet plug of welding cable to the output connection on the front panel

and turn clockwise. Earth clamp is used for connection of welding material to the chain of welding current.
