When the reversing switch lever is in the neutral position the switch trigger cannot be pulled CAUTION Always check the direction of rotation before operation Use the reversing switch only after the tool comes to a complete stop Changing the direction of rotation before the tool stops may damage the tool When not operating the tool always set the reversing switch lever to the neutral position Speed change Fig 5 To change the speed first switch off the tool and then slide the speed change lever to the 2 side for high speed or 1 side for low speed Be sure that the speed change lever is set to the correct position before operation Use the right speed for your job CAUTION Always set the speed change lever fully to the correct position If you operate the tool with the speed change lever positioned halfway between the 1 side and 2 side the tool may be damaged Do not use the speed change lever while the tool is running The tool may be damaged Adjusting the fastening torque Fig 6 The fastening torque can be adjusted in 17 steps by turning the adjusting ring so that its graduations are aligned with the pointer on the tool body The fastening torque is minimum when the number 1 is aligned with the pointer and maximum when the marking is aligned with the pointer The clutch will slip at various torque levels when set at the number 1 to 16 The clutch is designed not to slip at the marking Before actual operation drive a trial screw into your material or a piece of duplicate material to determine which torque level is required for a particular application This can be installed on either side of the tool To install the hook insert it into a groove in the tool housing on either side and then secure it with a screw To remove loosen the screw and then take it out OPERATION CAUTION Always insert the battery cartridge all the way until it locks in place If you can see the red part on the upper side of the button it is not locked completely Insert it fully until the red part cannot be seen If not it may accidentally fall out of the tool causing injury to you or someone around you Hold the tool firmly with one hand on the grip and the other hand on the bottom of the battery cartridge to control the twisting action Screwdriving operation Fig 10 CAUTION Adjust the adjusting ring to the proper torque level for your work Place the point of the driver bit in the screw head and apply pressure to the tool Start the tool slowly and then increase the speed gradually Release the switch trigger as soon as the clutch cuts in CAUTION Make sure that the driver bit is inserted straight in the screw head or the screw and or bit may be damaged NOTE When driving wood screws predrill pilot holes to make driving easier and to prevent splitting of the workpiece See the chart Nominal diameter of wood Recommended size of pilot screw mm hole mm 3 1 2 0 2 2 ASSEMBLY 3 5 2 2 2 5 CAUTION Always be sure that the tool is switched off and the battery cartridge is removed before carrying out any work on the tool 3 8 2 5 2 8 4 5 2 9 3 2 4 8 3 1 3 4 5 1 3 3 3 6 Installing or removing driver bit or drill bit Fig 7 5 5 3 7 3 9 5 8 4 0 4 2 Turn the sleeve counterclockwise to open the chuck jaws Place the bit in the chuck as far as it will go Turn the sleeve clockwise to tighten the chuck 6 1 4 2 4 4 To remove the bit turn the sleeve counterclockwise Installing bit holder Optional accessory Fig 8 Fit the bit holder into the protrusion at the tool foot on either right or left side and secure it with a screw When not using the driver bit keep it in the bit holders Bits 45 mm long can be kept there Hook Optional accessory Fig 9 The hook is convenient for temporarily hanging the tool Drilling operation First turn the adjusting ring so that the pointer points to the marking Then proceed as follows Drilling in wood When drilling in wood the best results are obtained with wood drills equipped with a guide screw The guide screw makes drilling easier by pulling the bit into the workpiece Drilling in metal To prevent the bit from slipping when starting a hole make an indentation with a center punch and hammer at the point to be drilled Place the point of the bit in the indentation and start drilling 7
