12 | English
1 609 92A 0KZ | (14.5.14) Bosch Power Tools
Keep the measuring tool and the laser
target plate 13 away from cardiac pace-
makers. The magnets of the measuring tool
and laser target plate generate a field that can
impair the function of cardiac pacemakers.
Keep the measuring tool and the laser target plate 13
away from magnetic data medium and magnetically-
sensitive equipment. The effect of the magnets of the
measuring tool and laser target plate can lead to irrevers-
ible data loss.
Product Description and
Specifications
Please unfold the fold-out page with the representation of the
measuring tool and leave it unfolded while reading the operat-
ing instructions.
Intended Use
The measuring tool is intended for determining and checking
horizontal and vertical lines as well as plumb points.
Product Features
The numbering of the product features shown refers to the
illustration of the measuring tool on the graphic page.
1 Exit opening for laser beam
2 Operating mode button
3 Battery low indicator
4 On/Off switch
5 Magnets
6 Tripod mount 5/8"
7 Tripod mount 1/4"
8 Latch of battery lid
9 Battery lid
10 Laser warning label
11 Serial number
12 Laser viewing glasses*
13 Laser target plate
14 Measuring plate with stand*
15 Universal holder*
16 Tripod*
17 Case
* The accessories illustrated or described are not included as
standard delivery.
Technical Data
Assembly
Inserting/Replacing the Batteries
Alkali-manganese batteries are recommended for the
measuring tool.
To open the battery lid 9, slide the latch 8 in the direction of
the arrow and fold the battery lid up. Insert the batteries.
When inserting, pay attention to the correct polarity accord-
ing to the representation on the inside of the battery lid.
Point and line laser GCL 25
Article number
3 601 K66 B00
Working range
1)
–Laser lines
– Horizontal point beams
–Point beam, upward
– Point beam, downward
10 m
30 m
10 m
5m
Levelling accuracy
– Laser lines and horizontal
point beams
– Vertical point beams
±0.3 mm/m
±0.5 mm/m
Self-levelling range, typically ±4°
Levelling duration, typically
<4s
Operating temperature
–10 °C ... +50 °C
Storage temperature
–20 °C ... +70 °C
Relative air humidity, max.
90 %
Laser class
2
Laser type
635 nm, <1 mW
C
6
1
Tripod mount
1/4", 5/8"
Batteries
4 x 1.5 V LR06 (AA)
Battery life for the operating
modes
– Cross and point-line operation
– 5-point operation
– Line operation
12 h
24 h
30 h
Weight according to
EPTA-Procedure 01/2003
0.6 kg
Dimensions
(length x width x height) 155 x 56 x 118 mm
Degree of protection
IP 54 (dust and splash
water protected)
1) The working range can be decreased by unfavourable environmental
conditions (e.g. direct sun irradiation).
The measuring tool can be clearly identified with the serial number 11
on the type plate.
OBJ_BUCH-1546-003.book Page 12 Wednesday, May 14, 2014 4:32 PM
