Bosch GDR 10,8-LI Professional БЕЗ АКК. [21/247] Maintenance and service

English | 21

Bosch Power Tools 2 609 140 699 | (3.12.09)

Reference Values for Maximum Screw/Bolt Tightening Torques

Calculated from the tensional cross-section; utilization of the yield point 90% (with friction coeffi-

cient μ

total

= 0.12). As a control measure, always check the tightening torque with a torque wrench.

Tips

Before screwing larger, longer screws into hard

materials, it is advisable to predrill a pilot hole

with the core diameter of the thread to approx.

of the screw length.

Maintenance and Service

Maintenance and Cleaning

f Before any work on the machine (e. g.,

maintenance, tool change, etc.) as well as

during transport and storage, set the rota-

tional direction switch to the centre posi-

tion. Unintentional actuation of the On/Off

switch can lead to injuries.

f For safe and proper working, always keep

the machine and ventilation slots clean.

When the battery is no longer operative, please

refer to an authorised after-sales service agent

for Bosch power tools.

If the machine should fail despite the care taken

in manufacturing and testing procedures, repair

should be carried out by an after-sales service

centre for Bosch power tools.

In all correspondence and spare parts order,

please always include the 10-digit article

number given on the type plate of the machine.

After-sales Service and Customer

Assistance

Our after-sales service responds to your ques-

tions concerning maintenance and repair of your

product as well as spare parts. Exploded views

and information on spare parts can also be

found under:

www.bosch-pt.com

Our customer service representatives can an-

swer your questions concerning possible appli-

cations and adjustment of products and acces-

sories.

Great Britain

Robert Bosch Ltd. (B.S.C.)

P.O. Box 98

Broadwater Park

North Orbital Road

Denham

Uxbridge

UB 9 5HJ

Tel. Service: +44 (0844) 736 0109

Fax: +44 (0844) 736 0146

E-Mail: boschservicecentre@bosch.com

Ireland

Origo Ltd.

Unit 23 Magna Drive

Magna Business Park

City West

Dublin 24

Tel. Service: +353 (01) 4 66 67 00

Fax: +353 (01) 4 66 68 88

Property Classes ac-

cording to DIN 267

Standard Screws/Bolts High-strength

Bolts

3.6 4.6 5.6 4.8 6.6 5.8 6.8 6.9 8.8 10.9 12.9

M 6

2.71 3.61 4.52 4.8 5.42 6.02 7.22 8.13 9.7 13.6 16.2

M 8

6.57 8.7 11 11.6 13.1 14.6 17.5 19.7 23 33 39

M 10

13 17.5 22 23 26 29 35 39 47 65 78

M 12

22.6 30 37.6 40 45 50 60 67 80 113 135

OBJ_BUCH-1066-001.book Page 21 Thursday, December 3, 2009 9:10 AM
