Fubag HS 5500 Honda + BORA Keramik 20M [2/33] General safety
![Fubag HS 5500 Honda + BORA Keramik 20M [2/33] General safety](/views2/1213435/page2/bg2.png)
- 1 -
Connections for standby power to a building's electrical system must be
made by a qualified electrician and must comply with all applicable laws and
electrical codes. Improper connections can allow electrical current from the
generator to back feed into the utility lines. Such back feed may electrocute
utility company workers or others who contact the lines during a power
outage, and when utility power is restored, the generator may explode, burn
or cause fires in the building's electrical system.
WARNING!
WARNING!
WARNING!
WARNING!
1. General safety
Exhaust gas contains poisonous carbon monoxide.
Never run the generator in an enclosed area. Be sure to provide adequate
ventilation. When installed in ventilated protection are to be observed.
The muffler becomes very hot during operation and remains hot for a while
after stopping the engine.
Be careful not to touch the muffler while it is hot. Let the engine cool before
storing the generator indoors. The engine exhaust system will be heated
during operation and remain hot immediately after stopping the engine.
To prevent scalding, pay attention to the warning marks attached to the
generator.
Gasoline is extremely flammable and explosive under certain conditions.
Refuel in a well ventilated area with the engine stopped.
Keep away from cigarette, smoke and sparks when refueling the generator.
Always refuel in a well-ventilated location.
Wipe up spilled gasoline at once.
WARNING! BEFORE USING THE MACHINE READ THE INSTRUCTION MANUAL
CAREFULLY!
Our generators are designed to give safe anddependable service if operated
according to instructions.
Read and understand the anual before operating the generator . Failure to
do so could result in personal injury or equipment damage.
FUBAG
FUBAGm
www.fubag.ru
Omperator's anual
