MEASUREMENT FOUNDATION

ROBOT 40

Indirect measurement

Pythagorean measurement is used in the condition that the objective needing to be measured is covered or has no effective reecting

surface and can’t be measured directly.

Make sure you adhere to the prescribed sequence of measurement:

• All target points must be in a horizontal or vertical plane.

• The best results are achieved when the instrument is rotated about a xed point (e.g. with the positioning bracket fully folded out and

the instrument placed on a wall) or the instrument is mounted on a tripod.

• The minimum / maximum function can be used. The minimum value must be used for measurements at right angles to the target; the

maximum distance for all other measurements.

Indirect measurement – determing a distance using 2 auxilary measurements. E.g. When height and distance can’t be measured

directly.

Press button (2) 3 times. The symbol is displayed. The distance to be measured is blinking in the symbol triangle.

Press button (2) to take distance measuring . The result is displayed in the rst line.

Press button (2) to take distance measuring .

After pressing button (2) the result is displayed in the rst line. The result of the function is displayed in the second line.

Indirect measurement – measuring of right-angle edge length (using hypotenuse and right-angle edge length). E.g. When height

and distance can’t be measured directly.

Press button (2) 4 times. The symbol is displayed. The distance to be measured is blinking in the symbol triangle.

Press button (2) to take distance measuring ( hypotenuse). The result of the function is displayed in the rst line.

Press button (2) to take distance measuring (height of the triangle) . The result of the measurement is displayed in the rst line.

The result of the measurement is displayed in the second line.
