Do not remove warning labels or safety instructions.

Do not open instrument housing, do not change it’s construc-

tion or modication.

Do not stare at beam. Laser beam can lead to eye injury

(even from greater distances).

Do not aim laser beam at persons or animals.

Opening of the equipment by using tools (screwdrivers, etc.),

as far as not specically permitted for certain cases.

Inadequate safety precautions at the surveying site (e.g.

when measuring on the roads, construction sites and so on).

Use the instrument in the places where it could be danger-

ous: on the air transport, near manufacturers,

production facilities, in the places where the work of laser

distance meter can lead to the harmful effects on

people or animals.

Keypad

1. ON / Measuring

2. Digital Camera Button

3. Addition

4. Area / Volume

5. Reference / Time

COSMO 120

VIDEO

6. Angle / Stake out function

7. Clear / OFF

8. Indirect measurements

9. Substraction

10. Trapezoid

11. Menu / Equal Button

Display

The graphics screen of the measurement window is split into

different areas. The selected measuring function is shown at

the left top part. The measurement eld contains the previ-

ous measurement results. There are 5 rows on the display.

1. Current measurement function

2. Indicator of laser point

3. Indicator of selected reference point

4. Digital level

5. Indicator of Bluetooth

6. Battery power

7. Previous measurement

8. Result of previous measurement

9. Current measurement function and result

10. Function and the results of successive measurements
