27
PG-006_v01
Appliance elements (Fig. D)
1
Large burner
2
Medium burner
3
Small burner
4
WOK burner
5
Burner knobs with ignition switch
6
Pan support
7
Burner cap
8
Burner crown
9
Burner base
10
Ignitor
11
Flame failure safety device
Flame adjustment (Fig. C)
Flame adjustment should be performed by
a certifi ed installation technician.
1
Light the burner and set it to the minimum fl ame .
2
Remove the knob from the shaft.
3
Use a special screwdriver and adjust the fl ame by turning
the screw inside the shaft. As a result you will obtain a small,
uniform fl ame around the burner.
In the case of 3B/P (G30) gas the screw must be fully
screwed in (clockwise).
4
Replace the knob
Make sure that when the knob is turned rapidly from
maximum
to minimum , the fl ame does not go out.
5
Turn off the burner by turning the knob to position .
Operating the hob
LIGHTING
Turn the appropriate knob left to position . Press it all the
way in. After the burner is lit, hold the knob pressed in for
approx. 10 seconds.
If after approx. 15 seconds of holding the knob pressed
in the position the burner is not lit, wait at least one
minute and try again. If after a few attempts the burner
still cannot be lit, check if the burner crown and the cap
are put on correctly.
If the fl ame of the burner is accidentally put out, turn the
burner off by turning the knob to position , and wait
one minute before turning the burner on again.
To put out the fl ame, turn the knob to the position.
When you are not using the hob, make sure that the
knobs are in the closed position .
USING THE APPLIANCE
For maximum effi ciency and best gas consumption, follow
the recommendations below:
use cookware with a fl at bottom and a diameter ●
appropriate for a given burner, see table below:
BURNER COOKWARE DIAMETER
WOK
∅ 220-260 mm
LARGE
∅ 180-220 mm
MEDIUM
∅ 120-200 mm
SMALL
∅ 80-160 mm
after reaching the boiling temperature, set the knob to ●
the minimum position .
FEATURES
GAS HOB MODEL
ZPG6214XZ ZPG6134SZ ZPG6145XZ ZPG6155SZ ZPG6165XZ ZPG6175SZ ZPG6185XZ ZPG6194XZ ZPG6204SZ
DIMENSIONS
OF GAS HOB
DEPTH [mm] 521 521 521 521 510 510 500 510 510
WIDTH [mm] 580 580 580 580 580 590 580 580 580
HEIGHT [mm] 72 72 80 77 82 82 77 73 82
INSTALLATION
DIMENSIONS
OF THE
WORKTOP
OPENING
GŁĘBOKOŚĆ [mm] 490 490 490 490 490 490 470 490 490
SZEROKOŚĆ [mm] 560 560 560 560 560 560 550 560 560
NUMBER OF
GAS BURNERS
(PIECES)
BURNER
DIAMETERS
SMALL BURNER 1 -
∅ 45 1 - ∅ 45 1 - ∅ 45 1 - ∅ 45 1 - ∅ 55 1 - ∅ 55 1 - ∅ 55 1 - ∅ 55 1 - ∅ 55
MEDIUM BURNER 2 -
∅ 65 2 - ∅ 65 2 - ∅ 65 2 - ∅ 65 2 - ∅ 75 2 - ∅ 75 2 - ∅ 75 2 - ∅ 75 2 - ∅ 75
LARGE BURNER 1 -
∅ 90 1 - ∅ 90 – – – – – 1 - ∅ 100 1 - ∅ 100
WOK BURNER – – 1 -
∅ 130 1 - ∅ 130 1 - ∅ 130 1 - ∅ 130 1 - ∅ 130 – –
BURNER KNOBS WITH IGNITION
SWITCH
+++++++++
BURNER PLATE INOX SZKŁO-INOX INOX SZKŁO-INOX INOX SZKŁO INOX INOX SZKŁO
FLAME FAILURE SAFETY DEVICE +++++++++
