34 987-001_v01
7
Slide the juice channel (5) over the adjusting screw until
it snaps on the body (3) – “click”.
8
Attach the assembled juicer to the drive unit in the same
way as the mincer body.
9
Insert the bowl (7) and the pusher (8) – from the mincer
unit – onto the feeding tube.
10
Place the appropriate dishes for the juice and pomace
under the outlet of the juice channel (5) and the adjusting
screw (6).
11
Plug in the appliance.
12
Turn the appliance on by means of the switch button
(1a), and then feed the fruit, pushing with the pusher.
In order for the juice squeezing process to run
properly do not screw the adjustment screw
too deeply in the initial operation phase. �fter
assessing the amount of juice in the processed
fruits, adjust the screw in order to obtain an
adequate effectiveness and to avoid clogging
the appliance.
Observe the pomace dryness during squeezing. If it
●
is too dry, unscrew the adjusting screw (6), to avoid
clogging the appliance with the pomace.
The screw adjustment depends on the type of
processed fruits, in case of juicy and ripe fruits
adjust the screw deeper, and for fruits that
are not as juicy, the level of screw adjustment
should be lower.
If the screw adjustment does not provide an
adequate squeezing effectiveness, you can
process the pomace once again.
The clogging of the chamber outlet (in the
adjustment screw (6)) with the pomace of juicy
fruits can cause the ooding of the drive unit.
Unplug the appliance if the chamber outlet becomes
●
clogged. Pay special attention on the juice squeezing
process, make sure the screen openings are not clogged.
Disconnect the juicer from the drive unit (as in the case
of the mincer body), dismantle the juicer, clean (wash)
the juicer elements. Use the included brush to clean the
appliance, especially the screen.
Shredder
1
Fine grating disc
2
Coarse grating disc
3
Slicing disc
4
Pureeing disc
5
Locking tab
6
Body
7
Tray
8
Pusher
B
The shredder is equipped with two grating discs for ne
(1) and coarse (2) grates (cheese, carrot, celery, cooked
beetroots etc.). The slicing disc (3) is used to slice vegetables
(potatoes, cucumbers, onions, etc.). The purée disc (4) is
used to purée potatoes, beetroots, fruits, etc.
WORKING WITH THE SHREDDER
1
Pull the locking tab (5) and place one of the discs with
the clutch facing the inside of the body.
2
Snap the tab shut (5).
3
Assemble the shredder body (6) in the same way as the
mincer body.
Cut larger products into pieces.
●
Do not grind soft fruits with hard stones.
●
Switch off and unplug the appliance after operation.
●
Remove the remaining products from the inside of the
●
disc or body using a wooden spoon.
The blades of the discs do to require
renovation.
Quern grinder
1
Nut
2
Quern regulator
3
Body with handle
4
Internal quern
5
External quern
6
Worm
7
Grinder chamber
8
Pan
9
The groove of the body has to hit the protrusion of the
grind chamber
DEVICE DESCRIPTION
Presented device can be used to grinding such products as:
corns, oily seeds and the dry comestibles.
The quern grinder enables grinding of such products as:
wheat, oat, rice, granular coffee, all-spice, charlock, walnuts,
hazel-nuts dried mushrooms, almonds, soya. linseed,
buckwheat groats, peeled sunower seeds etc.
Don`t grind the oily products by the minimal
granulation set up. Grinding device can be
glued or blocked.
Device is not dedicated for grinding the
very hard products as f. e. dried pea, maize,
popcorn.
THE INSTALLATION OF THE GRINDER
ON THE DEVICE
1
When the grinder chamber is turned right through the
angle of 45, put the assembled grinder on the drive by putting
the protrusions of grinder chamber (VII) on the recesses of
J
K
M
