Hyundai Robex 200W-7 [168/178] Head and work light circuit

4-11

4. HEAD AND WORK LIGHT CIRCUIT

OPERATING FLOW

Fuse box (No.15) I/conn 〔CN-7(8)〕 Switch panel 〔CN-116(10,11)〕

Fuse box (No.16) I/conn 〔CN-7(7)〕 Switch panel 〔CN-116(9)〕

Main light switch ON : 1st step

Head light switch ON 〔CN-116(2,3)〕 l/conn 〔CN-7(2)〕 l/conn〔CN-97(11)〕

Mutifunction sw left lever(3) (5) 〔CN-97(10)〕 Head light ON〔CL-3(1), CL-4(1)〕

: Head lamp ON

Main light switch ON : 2nd step

Work light switch ON 〔CN-116(14)〕 l/conn 〔CN-7(11)〕 l/conn 〔CN-3(1), (4)〕

I/conn〔CN-12(1)〕 Work light ON 〔CL-5(2), CL-6(2)〕

CHECK POINT

※ GND : Ground

(1)

(2)

Engine Start switch Check point

Voltage

STOP ON

ONSTOP

① - GND(Fuse box)

② - GND(Switch power input)

③ - GND(Switch power output)

④ - GND(Head light)

⑤ - GND(Fuse box)

⑥ - GND(Switch power input)

⑦- GND(Switch power output)

⑧ - GND(Work light)

20~25
