SP3000
Safety
22 / 87 BA 8034_2.4_EN (12/2016)
www.troteclaser.com
2.6 Safety devices
WARNING
Danger from laser beam
Safety and protection devices that are not installed or are not fully functional can lead to
bodily injury and material damage.
- Do not remove, modify or deactivate the safety interlock switches or protective covers
on the machine. Safety and protection devices must be fully functional at all times.
- In case of assumed or presumed damage of safety devices, disconnect the machine
from the mains.
- Damaged safety and protection devices need to be replaced by a Trotec technician
immediately.
2.6.1 Overview
The machine is equipped with the following safety devices:
Key switch
Emergency stop
Reflector
Main switch
Emergency stop
Emergency stop
Dust protections belt
Reflector
Micro switch
Hall sensor
Laser deflector shield
Emergency stop
Reflector
Side panel
Front cover
Side panel
Back cover
Light sensor
Bumper
Emergency
stop
Light curtain
Bumper
Micro switch
Light sensor
Warning lamp
Light sensor
Light curtain
