SP3000
Technical Data
BA 8034_2.4_EN (12/2016) 31 / 87
www.troteclaser.com
4 Technical Data
4.1 Data sheet
Mechanics
Working area
2.210 x 3.210 mm (87 x 126 in)
Loading area
2.500 x ∞ mm (98 x ∞ in)
Max. height of work piece
50 mm (1.96 in)
Working head
Software controlled z-axis
Working table
Slat cutting table, aluminum cutting grid table, acrylic cutting grid table
or honeycomb cutting table
Max. processing speed
1 m/s (40 ips) (standard); 2 m/s (79 ips) (optional)
Acceleration
10 m/s² (393 ips²)*
Motors
Brushless DC servo motors
Encoder
Incremental measuring system
Optical elements
Telescope, lens and all mirrors air-flushed protected from soiling
Lens
2.5" (standard); 3.75“, 5.0" (optional)
Accuracy
+/- 0,1 mm (0.004 in), over the whole working area
Addressable accuracy
0,001 mm (0.00004 in)
Accuracy to size of parts
According to material and process
Maximum material load
200 kg (440 lbs.), load over the whole working area
InPack Technology
TM
Protects working head and all moving parts from dust; harsh
environment protection kit included
Exhaust
Table exhaust for entire working area
Gas-Kit
Control of compressed air and process gas with max. 6 bar (87 psi),
built in filter-unit (free of mechanical dust, water and oil, max. flow rate
240 l/min, max. input 10 bar (145 psi), hose diameter 6 mm (0.23 in))
Software
JobControl
®
Expert
Interface
USB, RS-232 / ASCII, HPGL, AD-Logic System
Operating console
Keypad, safety-switch, system turnkey; workspace for mouse,
keyboard, monitor, drawer for tools; PC and Monitor not included
* Depending on configuration
