SP3000

Safety

24 / 87 BA 8034_2.4_EN (12/2016)

www.troteclaser.com

2.6.7 Bumper and micro switch

The spring-loaded bumper and corresponding micro switch provide object detection.

If an object gets detected the safety circuit is interrupted and subsequently the movement of the axis,

the current job processing and the laser emission stop immediately.

2.6.8 Light curtain

The light curtain provides access detection for hazardous areas. It is located in front of the X-axis and

is 16 cm (6.29 inch) high.

If an object gets detected the safety circuit is interrupted and subsequently the movement of the axis,

the current job processing and the laser emission stop immediately.

2.6.9 Laser deflector shield and hall sensor

The laser deflector shield absorbs a majority of scattered or reflected radiation in the area of the laser

beam output and is therefore mandatory during operation.

The presence of the magnetically fixed laser deflector shield is monitored via hall sensors. If the laser

deflector shield was removed on purpose or due to collision with a work piece, the safety circuit is

interrupted and subsequently the movement of the axis, the current job processing and the laser

emission stop immediately.

2.6.10 Light sensor and reflector

The light sensor and reflector provide access detection for hazardous areas. If an object gets detected

the safety circuit is interrupted and subsequently the movement of the axis, the current job processing

and the laser emission stop immediately.

2.6.11 In case of safety device malfunction

In case of actual or presumed damage to the safety devices:

 Press the emergency stop button

 Disconnect the machine from the mains

 Please contact your local Trotec Support
