SP3000
Safety
BA 8034_2.4_EN (12/2016) 27 / 87
www.troteclaser.com
2.8.3 Reflecting material
WARNING
Danger from laser beam
Invisible laser radiation of reflecting materials can cause serious injury or material damage.
- Only material according to the intended use of the machine may be used
- Do not use material with high reflecting surfaces such as aluminum, chromium, precious
metals, metal foils, stainless steel, brass, copper and titanium
- Take special care with surfaces formed convex and concave
- Do not leave or put objects on the work surface / working area
2.8.3.1 Laser beam reflection
The reflecting law is valid for the reflection of the laser radiation: Angle of incidence = failure corner
No
Description
1
Directed reflection
Reflected ray on smooth
surface
2
Directed reflection
Reflected ray on sloping
surface
3
Diffuse reflection
Reflected ray on rough
surface
4
Directed reflection
Horizontally reflected ray
on smooth surface
1
2
3
4
