SP3000

Operation

BA 8034_2.4_EN (12/2016) 65 / 87

www.troteclaser.com

8.6.3 Software focus

The following values must be entered in JobControl

 Table type

 Lens type

 Material thickness (exact measurement)

 Material process type

The values entered must match the material, table and lens in the machine in order to

avoid a head crash.

When using spacer the total material thickness is determined by the thickness of the

spacer and the material.

1. Click on the icon "Options" or go to

Settings/Options in the menu.

2. Select "Accessories".

3. When you are using a cutting table

enter the table type and the thickness

of the table.

4. Select the lens type in the menu bar.

5. Click on the icon "Material

database" or got to Settings/Material

database in the menu.

6. Enter the material thickness.

7. Enter the process type.

8. Click on the icon “Focus laser".

The working table moves automatically

to the correct position (moves in Z

direction).
