Trotec SpeedMarker 100 [3/4] One software package for all your needs speedmark

Additional lenses

Lenses of focal length F 100, F 254, F 330 and F 420 are

available in addition to the standard F 160 lens. This enables you

to vary the size of the marking field at any time. You are

therefore optimally equipped for all needs.

Automatic and programmable door

For faster and even more ergonomic part handling the

SpeedMarker 700 and 1300 are equipped with an automatic

door. The electrical door can also be programmed via the Speed

Mark software in order to further optimize the production

process.

MOPA laser

Select different pulse durations (pre-defined pulse shapes from 4

- 200 ns) and increase the possibilities for marking metals and

plastics.

Modular concept

Choose the system size that fits best to your application. In

addition, the housing of a SpeedMarker system can be

fitted with a pass-through hatch and removable side

covers on request making it possible to mark larger and

bulkier workpieces (the system is then classified as laser

class 4). A SpeedMarker system can also be extended by

using handling options such as conveyor belts or rotary

tables.

Rotary unit

An optional rotary unit with a selection of chucks is

available for engraving circular or conical objects such as

rings or tubes. It is also controlled using the laser software.

Developed for automated marking processes, the SpeedMark

provides program modules for typical marking tasks

(e.g. producing serial numbers or codes). These are easy

to adjust and allow the creation of tailor-made marking

programmes using graphical flow control. From simple direct

input to fully automated marking, everything is possible –

with no need for any special programming knowledge.

• Automatic, consecutive barcode generation

• Customizable user interfaces

• Material database for managing marking parameters

• Management of various user rights

• Interfaces to external systems such as databases

• Deep engraving function and processing of dynamic data

One software package for all your needs: SpeedMark

Individual marking programs easily designedSpeedMark user interface

SpeedMarker 700

• Medium sized all-round laser marking workstation

• Automatic door for efficient part handling

• Software-controlled axes, rotary table, …

SpeedMarker 1300

• Large format galvo laser workstation

• Marking of large and heavy parts or high volume parts in trays

• Highest flexibility due to software controlled X- and Y-axis

Trotec SpeedMarker 100 [3/4] One software package for all your needs speedmark
