Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 11 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
Class 1
The accessible laser radiation of Class 1 laser systems does not pose
any hazard for the skin or eyes.
In order to operate the Promarker as a Class 1 laser system, the
following points must be observed:
• The entire course of the beam should be shielded to
prevent radiation.
• Any covers providing access to laser areas which may be
removed without using a tool should be fitted with suitable
safety latches.
• Inspection windows in the housing should be fitted with
safety glass suitable for the laser output and the wave
length of the laser (DIN EN 207)
Class 2
The accessible laser radiation of Class 2 laser systems does not pose
any hazard for the skin. Any short-term radiation of the eyes also
poses no risk due to the low level output. In the event of longer, more
intensive radiation, the eye is protected by the natural lid reflex.
The Promarker uses a Class 2 pilot laser. In order to prevent irritation
of the eyes during operation, the operator should not look directly at
the laser source.
Diffuse reflections of the pilot laser are entirely harmless.
4.2 Gases, Fumes and Dust
Depending on the materials being marked and the parameters
selected, laser marking may generate gases, fumes, aerosols or dust.
The toxicity of such by-products depends on the material.
The operator is responsible for ensuring a suitable extraction system is
in place and for compliance with the relevant guidelines in order to
protect individuals and the environment. Instructions may be found in,
among others, the guidelines of the Association of German Engineers
VDI 2262 1...3 “Workplace air; reduction of exposure to air pollutants”.
The operator must also ensure that gases, fumes or dust do not settle
on the processing lens. Any dirt accumulating on the processing lens
can lead to a loss of performance, poor marking results and damage
to the device.
