DoCash DVM mini [4/5] Конструкция прибора

Control keys

Regulators and connectors on the back panel

Power supply is located on the back panel of the device.

1 2 3 4

Power supply

1 Contrast/

Contrast regulator

2 Bright-

ness/ Less

Brightness regulator

3 ON/OFF/

special ele-

ment “М”

Switch on/switch off

Special element “M”

1 2 3

Build instruction

1. Put the stand on a flat horizontal surface.

2. Insert power cable through the hole, disposed on the stand.

3. Put power cable into the power supply.

4. Secure the detector’s body on the stand until it snaps shut.

Конструкция прибора

Внешний вид

Корпус детектора

Настольная подставка

Управляющие клавиши

4,3” ЖК дисплей для вывода изображения

Зона расположения банкнот
