![Airwell VH2N 24 [12/16] Dimensional data mm and weight vh2n 03](/img/pdf.png)
Airwell VH2N 24 [12/16] Dimensional data mm and weight vh2n 03
![Airwell VH2N 05 [12/16] Dimensional data mm and weight vh2n 03](/views2/1408150/page12/bgc.png)
Page 12
Dimensional Data (mm) and Weight - VH2N 03
Unit size Operating weight Weight definition Ø Ø1 Ø2
VH2N 03 20 kg Unit with 4-row coil, without valve and without control. 1/2" female 1/2" female 1/2" female
23.5
125
125
143
23
692
Ø1
Ø1
Ø2
Ø2
ØØ
92
72
188
43.3
30
27
125
140
522
600
640
527.5
100
200
4-pipe unit
2-pipe unit
