Physical Data - VLC STD/HSE - ELN Version
VLC STD/HSE-ELN models 524 604 704 804 904 1004 1104 1204
Nominal cooling capacity (1) kW 144.0 164.5 188.5 211.0 244.0 264.5 292.0 319.0
Input power (2) kW 52.5 57.0 69.0 76.5 86.5 91.5 108.0 127.0
Number of refrigerant circuits 2 2 2 2 2 2 2 2
Total capacity steps %
25-50
75-100
28-57
78-100
20-50
70-100
25-50
75-100
28-50
78-100
25-50
75-100
23-50
73-100
25-50
75-100
COMPRESSORS
Number 4 4 4 4 4 4 4 4
Type
SCROLL
Oil type POE
N° of loading stages 0/100 0/100 0/100 0/100 0/100 0/100 0/100 0/100
AIR COOLED CONDENSER
Number of coils 2 2 2 2 2 2 2 2
Total coil face area per coil
m
2
3.5 3.5 4.8 4.8 4.8 4.8 4.8 4.8
FANS
Number of fans 2 3 3 3 4 4 4 4
Nominal speed rpm 550 550 550 550 550 550 550 550
Total airflow
m
3
/h 28300 38500 41800 41800 52000 48900 46200 46200
Total input power
kW 2 3 3 3 4 4 4 4
Total input power
(*) kW 0.6 0.9 0.9 0.9 1.2 1.2 1.2 1.2
External static pressure Pa 0
REFRIGERANT CONNECTION
In inch 7/8" 7/8" 7/8" 7/8" 1 1/8" 1 1/8" 1 1/8" 1 1/8"
Out inch 1 5/8" 1 5/8" 1 5/8" 1 5/8" 2 1/8" 2 1/8" 2 1/8" 2 1/8"
WEIGHT
Shipping weight kg 1110 1335 1525 1650 1735 1865 1950 1960
ADDITIONAL WEIGHT
HSE version kg 30 30 30 30 40 40 40 40
SOUND LEVELS
Sound power level (3) dB(A) 83 83 83 83 84 84 85 85
Sound pressure level - (10m) (4) dB(A) 51 51 51 51 52 52 53 53
DIMENSIONS
Length
mm 3300 3300 4300 4300 4300 4300 4300 4300
Width mm 1100 1100 1100 1100 1100 1100 1100 1100
Height mm 2300 2300 2300 2300 2300 2300 2300 2300
(1) Data based on 7 °C evaporating temperature and 35 °C ambient air temperature.
(2) Compressors only.
(3) Sound levels are at fully loaded conditions. Sound power level values refer to ISO standard 3744 and Eurovent 8/1.
(4) Sound pressure levels refer to ISO standard 3744, parallelepiped shape.
(*) High efficiency units (HSE) with inverter fans.
