Page 23
SWR
Models
LWT
Evap.
(°C)
Condensing temperature (°C)
40 42 45 48 50
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
Cooling
Cap.
(kW)
Input
(kW)
Heat
rej.
(kW)
1002
5 293.0 70.8 363.8 284.2 74.4 358.6 271.4 79.7 351.0 259.1 84.9 344.0 251.2 88.4 339.6
6 302.8 71.6 374.4 293.9 75.1 369.0 280.9 80.5 361.3 268.3 85.7 354.1 260.4 89.2 349.5
7 312.8 72.4 385.2 303.6 76.0 379.6 290.5 81.3 371.8 277.7 86.6 364.3 269.6 90.0 359.7
8 323.0 73.2 396.2 313.7 76.8 390.5 300.3 82.1 382.5 287.3 87.4 374.8 279.0 90.9 369.9
9 333.2 74.1 407.3 323.9 77.7 401.6 310.2 83.0 393.3 297.2 88.3 385.4 288.6 91.8 380.4
10 343.7 75.0 418.7 334.2 78.6 412.8 320.3 83.9 404.2 307.0 89.2 396.2 298.3 92.7 391.0
11 354.4 75.9 430.3 344.6 79.5 424.2 330.6 84.9 415.5 317.0 90.1 407.1 308.2 93.6 401.8
12 365.1 76.9 442.1 355.2 80.5 435.7 340.9 85.9 426.7 327.2 91.1 418.3 318.1 94.6 412.7
13 375.9 77.9 453.8 366.0 81.5 447.5 351.6 86.8 438.4 337.4 92.1 429.5 328.3 95.6 423.8
14 387.0 79.0 465.9 376.9 82.6 459.4 362.1 87.9 450.0 349.3 93.3 442.6 338.7 96.6 435.3
15 398.2 80.0 478.2 387.9 83.6 471.5 372.9 89.0 461.9 358.4 94.2 452.6 349.0 97.6 446.6
1202
5 315.2 76.1 391.3 305.8 79.9 385.7 292.0 85.6 377.6 278.7 91.3 370.0 270.3 95.0 365.2
6 325.8 76.9 402.7 316.2 80.7 397.0 302.2 86.5 388.7 288.7 92.1 380.8 280.1 95.8 376.0
7 336.6 77.8 414.4 326.7 81.7 408.4 312.6 87.3 399.9 298.8 93.0 391.9 290.1 96.7 386.8
8 347.5 78.7 426.2 337.6 82.5 420.1 323.1 88.2 411.4 309.1 94.0 403.1 300.2 97.7 397.9
9 358.5 79.7 438.1 348.5 83.5 432.0 333.8 89.2 423.0 319.7 94.8 414.6 310.5 98.6 409.1
10 369.8 80.6 450.4 359.6 84.4 444.0 344.6 90.2 434.8 330.3 95.9 426.1 321.0 99.6 420.6
11 381.3 81.6 462.8 370.8 85.5 456.3 355.7 91.2 446.9 341.1 96.9 437.9 331.6 100.6 432.2
12 392.8 82.7 475.5 382.2 86.5 468.7 366.8 92.3 459.0 352.0 97.9 449.9 342.3 101.6 443.9
13 404.5 83.7 488.2 393.8 87.6 481.4 378.3 93.3 471.6 363.0 99.0 462.0 353.2 102.7 455.9
14 416.4 84.8 501.2 405.5 88.7 494.2 389.6 94.4 484.1 375.8 100.3 476.0 364.4 103.8 468.2
15 428.4 86.0 514.4 417.4 89.9 507.2 401.2 95.6 496.8 385.6 101.2 486.8 375.5 104.9 480.3
1402
5 349.8 85.3 435.1 339.4 89.5 428.9 324.1 95.9 420.0 309.3 102.2 411.6 299.9 106.4 406.4
6 361.5 86.2 447.8 350.9 90.5 441.4 335.4 96.9 432.2 320.4 103.2 423.6 310.9 107.4 418.3
7 373.5 87.2 460.7 362.6 91.5 454.1 346.9 97.9 444.8 331.6 104.2 435.9 321.9 108.4 430.3
8 385.6 88.2 473.8 374.6 92.5 467.1 358.6 98.9 457.5 343.1 105.3 448.4 333.2 109.4 442.6
9 397.8 89.2 487.1 386.7 93.5 480.3 370.4 100.0 470.4 354.8 106.3 461.1 344.6 110.5 455.1
10 410.4 90.3 500.7 399.1 94.6 493.7 382.5 101.1 483.5 366.5 107.4 473.9 356.2 111.6 467.8
11 423.1 91.4 514.5 411.5 95.8 507.3 394.7 102.2 496.9 378.5 108.5 487.0 368.0 112.7 480.7
12 436.0 92.6 528.6 424.1 97.0 521.1 407.0 103.4 510.4 390.7 109.7 500.3 379.9 113.9 493.7
13 448.9 93.8 542.7 437.1 98.1 535.2 419.8 104.6 524.4 402.9 110.9 513.8 392.0 115.1 507.0
14 462.1 95.1 557.1 450.0 99.4 549.4 432.4 105.8 538.2 417.0 112.3 529.4 404.4 116.3 520.7
15 475.4 96.4 571.8 463.2 100.7 563.9 445.3 107.1 552.4 428.0 113.4 541.3 416.7 117.5 534.2
1602
5 397.1 97.3 494.4 385.2 102.1 487.4 367.8 109.4 477.3 351.1 116.7 467.8 340.5 121.4 461.9
6 410.4 98.4 508.8 398.4 103.2 501.6 380.7 110.5 491.2 363.7 117.8 481.5 352.9 122.5 475.4
7 424.0 99.5 523.4 411.6 104.4 516.0 393.8 111.7 505.4 376.5 118.9 495.4 365.5 123.7 489.1
8 437.7 100.6 538.3 425.2 105.5 530.7 407.1 112.8 519.9 389.4 120.1 509.6 378.2 124.9 503.1
9 451.6 101.8 553.4 439.0 106.7 545.7 420.5 114.0 534.6 402.8 121.2 524.0 391.2 126.1 517.3
10 465.8 103.0 568.9 453.0 107.9 560.9 434.1 115.3 549.4 416.0 122.6 538.6 404.4 127.3 531.7
11 480.3 104.3 584.6 467.1 109.3 576.4 448.1 116.6 564.7 429.6 123.8 553.5 417.8 128.6 546.4
12 494.9 105.7 600.6 481.4 110.6 592.0 462.0 117.9 580.0 443.4 125.1 568.6 431.2 129.9 561.1
13 509.6 107.0 616.6 496.1 112.0 608.1 476.5 119.3 595.8 457.3 126.5 583.9 444.9 131.3 576.2
14 524.5 108.5 633.0 510.8 113.4 624.2 490.8 120.7 611.6 473.4 128.2 601.6 459.1 132.7 591.7
15 539.7 109.9 649.6 525.8 114.9 640.7 505.4 122.2 627.6 485.8 129.4 615.2 473.0 134.1 607.1
1902
5 493.8 118.1 611.9 479.0 124.0 603.0 457.4 132.8 590.2 436.6 141.6 578.2 423.4 147.4 570.8
6 510.3 119.4 629.7 495.3 125.3 620.6 473.4 134.2 607.5 452.2 143.0 595.2 438.8 148.7 587.5
7 527.2 120.8 647.9 511.8 126.8 638.5 489.6 135.6 625.2 468.1 144.4 612.5 454.4 150.1 604.6
8 544.3 122.1 666.4 528.8 128.1 656.8 506.2 137.0 643.1 484.3 145.8 630.1 470.3 151.6 621.9
9 561.5 123.6 685.2 545.8 129.6 675.4 522.9 138.5 661.3 500.9 147.2 648.1 486.4 153.1 639.5
10 579.2 125.1 704.3 563.3 131.0 694.3 539.8 140.0 679.8 517.3 148.8 666.1 502.8 154.6 657.4
11 597.3 126.6 723.8 580.8 132.6 713.5 557.2 141.5 698.7 534.2 150.3 684.6 519.5 156.1 675.6
12 615.4 128.3 743.7 598.6 134.3 732.9 574.5 143.2 717.7 551.4 151.9 703.3 536.1 157.7 693.9
13 633.6 129.9 763.5 616.9 135.9 752.8 592.6 144.8 737.4 568.6 153.6 722.3 553.2 159.4 712.6
14 652.2 131.7 783.9 635.2 137.7 772.9 610.3 146.6 756.9 588.6 155.6 744.2 570.8 161.1 731.9
15 671.0 133.5 804.5 653.8 139.5 793.3 628.5 148.4 776.8 604.0 157.1 761.1 588.1 162.8 750.9
2202
5 604.6 140.8 745.4 586.6 147.8 734.4 560.1 158.3 718.4 534.7 168.8 703.5 518.5 175.7 694.1
6 624.9 142.3 767.3 606.6 149.4 755.9 579.7 159.9 739.6 553.8 170.4 724.2 537.4 177.3 714.6
7 645.6 143.9 789.5 626.7 151.1 777.8 599.6 161.6 761.2 573.2 172.1 745.3 556.5 178.9 735.4
8 666.6 145.5 812.1 647.5 152.7 800.2 619.8 163.2 783.1 593.0 173.8 766.8 575.9 180.7 756.6
9 687.7 147.3 835.0 668.4 154.4 822.9 640.3 165.0 805.3 613.3 175.4 788.8 595.6 182.4 778.1
10 709.3 149.1 858.4 689.8 156.2 846.0 661.1 166.8 827.9 633.5 177.3 810.9 615.7 184.2 800.0
11 731.4 150.9 882.3 711.3 158.1 869.4 682.3 168.7 851.0 654.2 179.2 833.4 636.1 186.1 822.2
12 753.6 153.0 906.5 733.0 160.1 893.1 703.5 170.7 874.2 675.2 181.1 856.3 656.6 188.0 844.5
13 775.9 154.8 930.8 755.4 162.0 917.4 725.6 172.6 898.3 696.4 183.1 879.5 677.5 190.0 867.5
14 798.7 156.9 955.6 777.9 164.1 942.0 747.4 174.7 922.1 720.8 185.5 906.3 699.0 191.9 891.0
15 821.7 159.1 980.8 800.6 166.3 966.8 769.6 176.8 946.5 739.7 187.2 926.9 720.2 194.0 914.2
LWT :
Leaving water temperature.
Cooling Capacities - SWR 1002 to 2202 - HFC 407C
