Chillers ULTIMA COMPACT
Chillers
Installation & Maintenance : 903-129 IM E 10/04/
C
21
Installation Data
GLYCOL DATA
Glycol is recommended when a supply water temperature of +5°C or below is required or
when static water can be exposed to freezing temperatures.
Ethylene Glycol Nominal Correction Factors
Glycol in System / Freezing Point ºC 10% / -4°C 20% / -9°C 30% / -15°C 40% / -23°C
Cooling Duty 0.98 0.97 0.95 0.93
Input Power 0.99 0.98 0.96 0.95
Water Flow 0.99 1.02 1.04 1.07
Pressure Drop
Catalogue Data x by:
1.05 1.20 1.38 1.57
Propylene Glycol Nominal Correction Factors
Glycol in System / Freezing Point ºC 10% / -2°C 20% / -6°C 30% / -12°C 40% / -20°C
Cooling Duty 0.97 0.95 0.91 0.88
Input Power 0.99 0.98 0.96 0.95
Water Flow 0.98 0.97 0.95 0.95
Pressure Drop
Catalogue Data x by:
1.08 1.17 1.31 1.45
Example UCC250D-6/2 operating at 7/12, 30°C Ambient, 20% Ethylene Glycol
Catalogue
Figure Multiplier
Corrected
Figure
Cooling kW (refer to Technical Manual) 269.2 x 0.97 261.1 kW
Input kW (refer to Technical Manual) 79.2 x 0.98 77.6 kW
(DX (Mechanical Cooling kW)
Flow l/s
calculated
∆T x 4.19
12.8 x 1.02 13.1 l/s
Pressure Drop kPa (refer to Waterside Pressure Drops) 50.0 x 1.20
20%
Ethylene
Glycol =
60.0 kPa
Waste glycol needs to be handled responsibly, recycled or turned over to professional
personnel for correct disposal. Most anti-freeze manufacturers recommend that used anti-
freeze be collected and disposed according to Local Legislation. Waste glycol should NOT be
drained onto the ground, rainwater drainage system or natural waters.
If the glycol contains heavy metals or other contaminants from gas or oil, the level of hazard
posed by the glycol is increased and could be characterised as hazardous waste.
STEPS IF GLYCOL IS RELEASED/SPILLED
Small spill - soak up with absorbent material.
CAUTION
Large spill - contain spill and pump to suitable container for disposal.
