Cleaning the oven door
Clean the glass part of the oven door using a sponge and a non-abrasive
cleaning product, then dry thoroughly with a soft cloth. Do not use rough
abrasive material or sharp metal scrapers as these could scratch the surface
and cause the glass to crack. For more thorough cleaning purposes, the oven
door may be removed:
1. Open the oven door fully (see diagram);
2. Lift up and turn the small levers located on the two hinges (see diagram);
Grip the door on the two external sides
and close it approximately half way.Pull
the door towards you lifting it out of its seat
(see diagram).
To replace the door, reverse this sequence.
Inspecting the seals
Check the door seals around the oven regularly. If the seals are damaged,
please contact your nearest Service Centre (see Assistance). We recommend
that the oven is not used until the seals have been replaced.
Replacing the light bulb
To replace the oven light bulb:
1. Remove the glass cover of the lamp-
holder.
2. Remove the light bulb and replace it with a
similar one: Wattage 25 W, cap E 14.
3. Replace the glass cover (see diagram).
! Do not use the oven lamp as/for ambient lighting.
Sliding Rack Kit assembly
To assemble the sliding racks:
1. Loosen the two screws A (see
diagram). If the oven is tted with self-
cleaning panels, these will have to be
temporarily disassembled.
A
A
2. Replace the screws A with the screws
and spacers (B + C) supplied with the kit.
3.Tighten the new screws B and the
corresponding spacers C, tting the self-
cleaning panels on again.
4. Secure the two joints D of the guide
rail in the holes provided on the oven
walls (see diagram). The holes for the
left guide rail are situated at the top,
while the holes for the right one are at
the bottom.
5. Finally, t the guide rail on the spacer
C.
! Do not place the sliding racks in position 5.
Side and rear catalytic liners
These are panels coated with a special enamel, which is able to absorb the
fat released by food as it cooks.
This enamel is quite strong, so that the various accessories (racks, dripping
pans, etc.) can slide along them without damaging them. White marks may
appear on the surfaces; these are not a cause for concern.
Nevertheless, the following should be avoided:
- scraping the enamel with sharp objects (a knife, for example);
- using detergents or abrasive materials.
C B
D
12
GB
