The Aspen Hi-Lift 1 & 2 litre Tank Pump

Suitable for any situation particularly high lift conditions.

Quiet operation.

Description:

The pump is designed to collect condensated water from Air Conditioning machines

and discharge it up to 12 metres head. The internal safety float is a low current switch

to stop the Air Conditioning System in the event of pump failure. The pump is

operated from an internal float switch.

Installation Notes:

Service Guide:

1 Inspect the pump head regularly and change the pump head tube every 12

months or more often if required.

2 Flush the pump through with anti-bacterial wash every 6 months to avoid sludge

build-up in the pump.

3 To remove the pump head, make sure that the roller assembly is vertical.

Remove the screws and fit the replacement pipe. The addition of a smear of

silicon grease will ease the refitting of the lid and reduce potential friction

noise.

4 Replacement pump head tubes and other accessories can be obtained from the

Tel: 01323 848842 Fax: 01323 848846 www.aspenpumps.com sales@aspenpumps.com

Technical

Specification:

•

2 metre connecting cable

•

Self-priming

•

Tank holds 1 litre or 2 litres

•

per hour at 12 metre discharge rate

•

Pre-wired safety switch: 4.0A

•

Temperature limits on pump

head tube: –30 to +100°C

•

Pump rating 0.4A, 230V AC

1 Litre: Height: 132mm Width: 235mm

Green/yellow: Earth

2 x Black: Safety Float
