EN
What is included in the box
Supply of this TV includes following parts:
• 1x TV • 1x Power cord
• 1x Remote control • 1x TV stand installation packet
• 2x AAA batteries • 1x User guide
• 1x mini component adapter
cable*
• 1x mini composite adapter
cable*
* - only for 32" models
Attaching the Stand
Please follow the instructions on last page of this user manual.
Wall mounting the TV
1. Remove the four screws that are supplied in the wall mounting holes.
2. The wall mount can now be easily attached to the mounting holes on
the rear of the TV.
3. Install the wall mounting bracket to the television as advised by the
bracket manufacturer.
Getting started - initial set up
1. Insert the batteries supplied into the Remote control.
2. Using the RF cable, connect the TV to the TV Aerial wall socket.
3. Connect the power cable to the rear of the TV, and then connect it to
the electrical outlet.
4. Then press Standby button to power on TV.
5. You will be now welcomed with the First Time Installation screen.
If it does not appear, on the remote control, please press [MENU] then
8-8-8-8 and the menu will appear.
If you wish to make changes to any of the default settings, use the
scroll ▲/▼/◄/► buttons. To exit this menu at anytime, press [EXIT]
button.
6. Please set desired settings in FIRST TIME INSTALLATION screen.
DVB Antenna - You can choose between Terrestrial (DVB-T/T2), Cable
(DVB-C) or Satellite (DVB-S/S2).
Language - Set the TV Menu language.
Country - Set the desired country.
Tunning Mode - Choose if you want to tune only Digital (DTV)
Analogue (ATV) or both Digital and Analogue (DTV + ATV)
Environment - Select the location of TV.
For home use, please select Home Mode.
For shop demonstration mode, set Store Mode.
Sorting by LCN - Set LCN to ON if you want to arrange channels by
provider preferences (only applies to DVB-T and DVB-C channels).
7. Press [OK] button to start the tuning process.
8. Optional channel presets DVB-C:
Keep all default settings as recommended.
If DVB-C channels are not found, contact your network provider for the
valid "Network ID". Then perform anew search. Press the [MENU], select
"Network ID" and enter the network ID.
9. Optional channel presets DVB-S2: Select "Satellite" in the "DVB
Antenna" in the menu for the optional channel presets. Here you can
choose between the various satellites. Since selection completed, then
the channel list of the exact satellite will be available to be imported
into your TV system.
Con rm with [OK] button on the remote control, to start scanning.
TIP: If you are missing channels, the reason for this is likely to be signal
strength, you should consider connecting signal booster and re-tuning the TV.
Remote control
1. STANDBY – Switch on TV when in standby or vice versa.
2.
MUTE – Mute the sound or vice versa.
3. DTV – Switch to digital TV source.
4. RADIO – Switch to Digital and switch between TV and radio in Digital
mode.
5. USB – Switch to USB source.
6. DVD – DVD
2
– Switch to DVD mode
7. 0 – 9 – to select aTV channel directly.
8. TV GUIDE – Opens the 7 Day TV Guide (Digital mode).
9.
– To return to the previous channel viewed.
10. VOL ▲/▼ – To increase / decrease the sound level.
11. S.MODE – Scrolls through sound mode options.
12. P.MODE – Scrolls through picture mode options.
13. FAV – To display favourites menu.
14. CH ▲/▼ – To increase or decrease the channel being watched.
15. (▲/▼/◄/►/ OK) – Allows you to navigate the on-screen menus and
adjust the system settings to your preference.
16. MENU – To display OSD menu.
17. EXIT – To exit all menus.
18. SOURCE – To display the input/source menu.
19. INFO – Press once for now/next channel information. Press twice for
programme information about current programme.
20. ASPECT – To switch the screen between the di erent picture formats.
21. SLEEP – Press repeatedly to cycle through the sleep options.
22. AUDIO – To change the audio language (if available).
23. SUBTITLE – To switch the dialogue at the bottom of the screen (on/
o ).
24. TEXT – Teletext mode - To enter Teletext
25. TEXT HOLD – Teletext mode - Hold current page which is displayed
26. TEXT/ DVD ZOOM
2
– DVD mode - Teletext Mode - To zoom in
27.
DISPLAY – To switch o the screen when listening to radio
28. Rec
1
/DVD MENU
2
– PVR Record / DVD mode - To display the DVD disc
menu
29. Rec List
1
/DVD SETUP
2
– Opens the list of recordings / DVD mode - To
display the DVD setup menu
30.
– To restart the current chapter
31.
– To advance forward to the next chapter
32.
/
– To stop the playback / To EJECT the disc press/hold the button
for 4 seconds.
33.
– To play in fast rewind mode.
34.
– To play in fast forward mode.
35.
– To play/pause
36. COLOUR BUTTONS
– Additional teletext and OSD functions
GOTO
2
– DVD mode - To go to a speci c chapter
A–B
2
– DVD mode - Press once to set point,
press a second time to return to point
ANGLE
2
– DVD mode - Select di erent angle of DVD (if available)
REPEAT
2
– DVD mode - USB mode -To repeat playback
1
- available only with PVR function
2
- available only for TVs with DVD player
TV Control Stick
TV control stick is located on the lower left corner of back side of the TV.
You can use it instead of remote control to control most of the functions
of your TV.
While TV is in standby mode:
