FBM-1 Specifications
■ Nominal Input Level -20 dBu ■ Input Impedance 1 MΩ ■ Nominal Output Level -20 dBu ■ Output
Impedance 2.2 kΩ ■ Recommended Load Impedance 10 kΩor greater ■ Controls Pedal Switch, PRESENCE
Knob, MIDDLE Knob, BASS Knob, TREBLE Knob, GAIN Knob, LEVEL Knob ■ Indicator CHECK Indicator
(Serves also as battery check indicator) ■ Connectors INPUT Jack, BRIGHT IN Jack, OUTPUT Jack, AC
adaptor Jack ■ Power Supply DC 9 V: Dry battery 6F22 (9 V) type (carbon), Dry battery 6LR61 (9 V) type
(alkaline), AC Adaptor (PSA series: optional) ■ Current Draw 36 mA(DC 9 V) ■ Expected battery life under
continuous use Carbon: 3 hours, Alkaline: 10 hours ■ Dimensions 73 (W) x 129 (D) x 59 (H) mm, 2-7/8 (W)
x 5-1/8 (D) x 2-3/8 (H) inches ■ Weight 440 g/ 1 lb (including battery) ■ Accessories Owner's Manual,
Leaflets (USING THE UNIT SAFELY, IMPORTANT NOTES, and Information), Dry Battery 006P/9V (6LR61)
■ Options AC Adaptor (PSA series)
* The battery that was supplied with the unit is for temporary use - intended primarily for testing its operation.
* We recommend that alkaline battery be used when replacing the battery.
* 0 dBu=0.775 Vrms
* The specifications are subject to change without notice.
FDR-1 Specifications
■ Nominal Input Level -20 dBu ■ Input Impedance 1 MΩ ■ Nominal Output Level -20 dBu ■ Output
Impedance 2.2 kΩ ■ Recommended Load Impedance 10 kΩ or greater ■ Controls Pedal Switch, GAIN
Knob, LEVEL Knob, TREBLE Knob, BASS Knob, VIBRATO Knob, REVERB Knob ■ Indicator CHECK Indicator
(Serves also as battery check indicator) ■ Connectors INPUT Jack, OUTPUT Jack, AC adaptor Jack
■ Power Supply DC 9 V: Dry battery 6F22 (9 V) type (carbon), Dry battery 6LR61 (9 V) type (alkaline), AC
Adaptor (PSA series: optional) ■ Current Draw 40 mA (DC 9 V) ■ Expected battery life under continuous
use Carbon: 2.7 hours, Alkaline: 9 hours ■ Dimensions 73 (W) x 129 (D) x 59 (H) mm/ 2-7/8 (W) x 5-1/8 (D)
x 2-3/8 (H) inches ■ Weight 440 g/ 1 lb (including battery) ■ Accessories Owner's Manual, Leaflets (USING
THE UNIT SAFELY, IMPORTANT NOTES, and Information), Dry Battery 006P/9V (6LR61) ■ Options AC
Adaptor (PSA series)
* The battery that was supplied with the unit is for temporary use
- intended primarily for testing its operation.
* We recommend that alkaline battery be used when replacing the battery.
* 0 dBu=0.775 Vrms
* The specifications are subject to change without notice.
Fender Bassman Pedal
●Recreates the legendary tone
of the 1959 Fender Bassman amp
●Additional BRIGHT IN provides
a brighter sound, similar to
the original Bassman
●Presence, Treble, Mid, and
Bass EQ controls
●Road-tough BOSS metal
construction
●Perfect pre-gain pedal for adding
or retaining Fender tone color
Fender® and BASSMAN® are the trademarks of FMIC.
All rights reserved.
*Actual product appearance may be subject to change.
Fender® and Deluxe Reverb® are the trademarks of FMIC.
All rights reserved.
*Actual product appearance may be subject to change.
Fender amps of the ’50s and ’60s are beloved and coveted by guitarists around the world. Thanks to BOSS’
technology and tone know-how, the new FBM-1 brings the natural, fat, rich, bright tone of the Fender
Bassman to a BOSS pedal. In conjunction with Fender, the new BOSS FBM-1 recreate the legendary tone of
1959 Fender Bassman. Features include the same controls on the original Bassman: Presence, Treble, Mid,
and Bass EQ controls. The FBM-1 also functions perfectly as a “pre-gain pedal” placed before an already
overdriven amp to add the tone character of the Bassman.
Fender Deluxe Reverb Amp Pedal
The second in the new Legend Series is the FDR-1, based on the Fender 1965-era Deluxe Reverb — a coveted
tube amp known for its natural touch-responsive and distinctive snappy overdriven sound. In conjunction with
Fender, BOSS designed this stompbox to recreate the legendary tone of the 1965 Fender Deluxe Reverb amp.
Features include the same controls on the original Deluxe Reverb; Level, Gain, Treble, Bass, Vibrato, and
Reverb. The FDR-1 also functions perfectly as a “pre-gain pedal” placed before an already overdriven amp to
add the tone character of the Deluxe Reverb.
15
●Recreates the legendary tone
of the 1965 Fender Deluxe
Reverb guitar amp
●Level, Gain, Treble, Bass,
Vibrato, and Reverb controls
●Road-tough BOSS metal
construction
●Perfect pre-gain pedal for
adding or retaining Fender tone
color
