![Yamaha DV-S5450 [19/23] Access control child lock dvd video and video cd](/img/pdf.png)
Yamaha DV-S5450 [19/23] Access control child lock dvd video and video cd
![Yamaha DV-S5450 [19/23] Access control child lock dvd video and video cd](/views2/1041322/page19/bg13.png)
15
English
Deciding the PIN number
When changing Access control settings, first decide your
PIN number. You need to enter the number whenever your
change the settings.
1 Select ACCESS CONTROL in the features menu using
3/4, and then press 2.
2 Enter your 4-digit code of your own choice.
3 Enter the code a second time.
1en1en 1 2
Access control
Status window
Low Power standby
PBC
[ ] [ ] [ ] [ ]
Enter code
Access Control: Child Lock
(DVD Video and Video CD)
Activating/deactivating the Child Lock
1 Select ACCESS CONTROL in the features menu using
the 3/4, and then press 2.
2 Enter your 4-digit code of your own choice.
3 Move to “CHILD LOCK” using the 3/4.
4 Move to LOCK/UNLOCK using the 2.
5 Select LOCK using the 3/4.
6 Press ENTER/OK or 1 to confirm, then press 1 again to
exit the menu.
➜ Now unauthorized discs will not be played unless the
4-digit code is entered.
7 Select UNLOCK to deactivate the CHILD LOCK.
1en1en 1 2
Access control
Status window
Low Power standby
PBC Change code
Change country
Parental level
Child lock
Authorizing discs
¶ Insert the disc. See ‘Loading discs’.
➜ The ‘child protect’ dialog will appear.
You will be asked to enter your secret code for ‘Playback
Once ‘or ‘Playback Always.’ If you select ‘Playback Once’, the
disc can be played as long as it is in the player and the
player is ON. If you select ‘Playback Always’, the disc will
become child safe (authorized) and can always be played,
even if the Child Lock is set to ON.
Notes:
– The player memory maintains a list of 80 authorized
(‘Child safe’) disc titles. A disc will be placed in the list when
‘Playback Always’ is selected in the ‘child protect’ dialog.
– Each time a ‘child safe’ disc is played, it will be placed on
top of the list. When the list is full and a new disc is added, the
last disc in the list will be removed from the list.
– Double-sided DVDs may have a different ID for each side.
In order to make the disc ‘child safe’, each side has to be
authorized.
– Multi-volume VCDs may have a different ID for each
volume. In order to make the complete set ‘child safe’, each
volume has to be authorized.
Access Control
Play once
locked
[ ] [ ] [ ] [ ]
Play always
Choose ’Play always‘ to insert the disk in
the child-safe list.
[ ] [ ] [ ] [ ]
Deauthorizing discs
¶ Insert the disc. See ‘Loading discs’.
➜ Playback starts automatically.
¶ Press 9 while { is visible.
➜ The | will appear and the disc is now deauthorized.
Note:
Playback continues even after you have deauthorized the disc.
Press 9 if you want to stop it.
Access Control: Parental
Control (DVD Video only)
Movies on DVDs may contain scenes not suitable for
children. Therefore, discs may contain ‘Parental Control’
information which applies to the complete disc or to
certain scenes on the disc. These scenes are rated from 1
to 8, and alternative, more suitable scenes are available on
the disc. Ratings are country dependent. The ‘Parental
Control’ feature allows you to prevent discs from being
played by your children or to have certain discs played with
alternative scenes.
ACCESS CONTROL
Access Control
