Yamaha DV-S5550 [26/27] Audio format
![Yamaha DV-S5550 [26/27] Audio format](/views2/1041327/page26/bg1a.png)
22
Specifications
PLAYBACK SYSTEM
DVD Video
DVD+RW
DVD+R
Video CD and SVCD
CD (CD-R and CD-RW)
MP3 CD
TV STANDARD (PAL/50Hz) (NTSC/60Hz)
Number of lines 625 525
Playback Multistandard (PAL/NTSC)
VIDEO PERFORMANCE
Video output 1 Vpp into 75 ohm
S-Video output Y: 1 Vpp into 75 ohm
C: 0.3 Vpp into 75 ohm
Component video output Y: 1 Vpp into 75 ohm
PB/CB PR/CR: 0.7 Vpp into 75 ohm
Black Level Shift On/Off
Video Shift Left/Right
AUDIO FORMAT
Digital MPEG
Compressed Digital
DTS/Dolby Digital
PCM 16, 20, 24 bits
fs, 44.1, 48, 96 kHz
Analog Sound Stereo
Dolby Pro Logic downmix from Dolby Digital multi-channel
sound
3D Sound (TruSurround) for virtual 5.1 channel sound on 2
speakers
AUDIO PERFORMANCE
DA Converter 24 bits
DVD fs 96 kHz 2 Hz - 44 kHz
DVD fs 48 kHz 2 Hz - 22 kHz
VCD/CD fs 44.1 kHz 2 Hz - 20 kHz
Signal-Noise (1kHz) 105 dB
Dynamic Range (1kHz) 100 dB
Distortion and Noise (1kHz) 0.0030%
MPEG MP3 MPEG Audio L3
CONNECTIONS
Y Output Cinch (green)
Pb/Cb Output Cinch (blue)
Pr/Cr Output Cinch (red)
S-Video Output Mini DIN, 4 pins
Video Output Cinch (yellow)
Audio L+R output Cinch (white/red)
Audio Subwoofer Cinch (black)
Digital Output 1 coaxial, 1 optical
IEC958 for CDDA / LPCM
IEC1937 for MPEG1/2, Dolby
Digital, DTS
GENERAL
Dimensions (w x h x d) 435 x 75 x 302 mm
Weight Approximately 2.8 Kg
POWER SUPPLY
U.S.A. and Canada models 120 V, 60 Hz
Australia model 240 V, 50 Hz
POWER CONSUMPTION 17 W
(3W in standby mode)
Specifications subject to change without prior notice.
