INSTALLATION

OPERATION

CONTROLLING TEMPERATURES

The refrigerator controls its temperature automatically. However, if needed, adjust the temperature as follows.

• If the refrigerator is operated for a long time with

FREEZER TEMP. CONTROL set at 7 (MAX), foods

stored in the refrigerator compartment may also freeze.

• If the refrigerator is operated for a long time with

REFRIGERATOR TEMP. CONTROL set at 7 (Coldest),

foods stored in the refrigerator compartment may also

freeze.

• Low ambient temperature may cause placed foods to

freeze even if REFRIGERATOR TEMP. CONTROL is

set to 1 (MIN).

HINTS WHEN MAKING ICE

1.Do not over fill the Ice cube trays; otherwise the ice

cubes will be joined together when frozen.

2.When the ice cubes are

made, turn the lever clock-

wise to empty the ice into

the Ice cube box.

NOTE:

To prevent damage to the Ice cube box, do not make ice in

the Ice cube box or pour oil into it.

Keep adequa

e ventilation space

around the refrigerator.

•

The figure shows the minimum

required space for installing the

refrigerator. It differs from the space

in the measurement condition of the

amount of power consumption.

•

It is possible to use the refrigerator

with a less amount of power

consumption by keeping greater

space.

•

If using the refrigerator in the space

below dimension of the figure, it

may cause the temperatures in the

unit to rise, loud noise, and failure.

2.Using the two front Adjustable feet,

ensure that the refrigerator is posi-

tioned firmly and level on the floor.

When transporting

1. Before transporting, wipe dry

any water in the

Evaporating pan

located on the rear.

2. Carry the refrigerator by holding

the handles located on the rear

and bottom.

Before using your refrigerator

Clean the inside parts with a cloth

soaked in warm water. If soapy

water is used, wipe it off thoroughly.

NOTE:

• Position your refrigerator so that the plug is accessible.

• Keep your refrigerator out of direct sunlight.

• Do not place next to heat generating appliance.

• Do not place directly on the ground. Provide suitable stand.

Foot

Adjustable

foot

cover

60 mm

or more

60 mm

or more

90 mm or more

1210 mm

1320 mm

7(MAX)

For making ice rapidly or fast freezing.

4(MED)

For normal freezing.

1(MIN)

When frozen food or ice cream is not stored.

Freezer

compartment

7(Coldest)

For keeping foods fresher tasting. When the refrigerator

does not provide sufficient cooling.

4(MED)

For normal operation.

1(MIN)

When the refrigerator provides excessive cooling.

Refrigerator

compartment

Ice cube box

Lever
