www.timberk.com • instant water heater
4
Table 1a
ATTENTION!
The water heater shall be certainly grounded.
3. APPLICATION OF WATER HEATER
4. SPECIFICATIONS
Electric water heater is used to heat cold water from water supply. Unit is
for household use.
The water heater shall be operated only with an original shower nozzle and/or
kitchen spout excluding their clogging.
25. The water heater is designed only for heating of water. Do not use the
product for heating of other liquids. This may inflict a severe damage to the
water heater.
26. Do not connect electric wires of the device to a water pipeline, a gas
pipeline, etc.
27. Make sure in proper connection of electric wiring (including grounding
loop).
28. Before use, make sure that parameters of your electric mains meet the
specifications of this water heater.
29. Inlet temperature of water shall not exceed +35°C.
30. For use of the water heater in a bathroom, it is recommended to install it
above body height so that water splashes do not get onto its enclosure.
It is expressly PROHIBITED to
• Pull electric wires inside the water heater;
• Remove the enclosure of the water heater, when it is energized;
• Install other fixtures, except for fixtures recommended by the
manufacturer;
Specifications for different series of water heaters are given in Tables 1a, 1b,
1c.
Parameter
Unit of
measuremen
WHEL-3 OC WHEL-3 OS WHEL-3 OSC
Version - crane shower shower+crane
Power supply parameters V/Hz 220~/50 220~/50 220~/50
Rated current A
16 16 16
Power by steps kW 0/3,5 0/3,5 0/3,5
Rated power consumption kW 3,5 3,5 3,5
Operating pressure Mpa 0,03 - 0,6 0,03 - 0,6 0,03 - 0,6
Flow rate (at t=20°C)
L/min
1,9 1,9 1,9
Protection class - I I I
Water protection class - IPX4 IPX4 IPX4
Wire section of electric connection
cabel
mm2 3 х 1,5 3 х 1,5 3 х 1,5
Dimensions
mm (H х W
х H)
159x272x112 159x272x112 159x272x112
Net weight kg 1,35 1,35 1,35
