28
GB
~
• The effect may not function or may vary depending on the programme regardless of the
“Dynamic Range” setting.
“Optical Out”: Sets the audio signal that is output from the DIGITAL AUDIO
OUT (OPTICAL) jack of the TV. Set to “Auto”, when connecting equipment
compatible with Dolby Digital. Set to “PCM”, when connecting equipment not
compatible with Dolby Digital.
“MPEG Audio Level”: Adjusts the MPEG audio sound level.
“Downmix Mode”: Set the dowmix method of multi-channel to two-channel sound.
• “Surround”: Select to get best surround performance, or while using external products with
Pro Logic.
• “Stereo”: Select to get a stereo output.
Parental Lock
Sets an age restriction for programmes. Any programme that exceeds the age
restriction can only be watched after a PIN Code is entered correctly.
~
• For cable operators in Netherlands, the PIN code should be entered when the programme
rating is above or equal to the age you specify.
1 Press the number buttons to enter your existing PIN code.
If you have not previously set a PIN, a PIN code entry screen appears. Follow the
instructions of “PIN Code” below.
2 Press F/f to select the age restriction or “None” (for unrestricted
watching), then press .
3 Press RETURN.
PIN Code
To set your PIN for the first time
1 Press the number buttons to enter the new PIN code.
2 Press RETURN.
To change your PIN
1 Press the number buttons to enter your existing PIN code.
2 Press the number buttons to enter the new PIN code.
3 Press RETURN.
z
• PIN code 9999 is always accepted.
Technical Set-up
“Auto Service Update”: Enables the TV to detect and store new digital services as
they become available.
“System Update”: This TV set is capable of receiving software upgrades via the
broadcast signal. In order to receive upgrades the System Update option in the
Technical Setup menu should be set to “On”. When an upgrade is detected the user
will be informed by a series of on screen displays on how to proceed with the
upgrade. Please do not disconnect the set from the mains during the installation
procedure.
“System Information”: Displays the current software version and the signal level.
“Time Zone”: Allows you to manually select the time zone you are in, if it is not the
same as the default time zone setting for your country/region.
~
• When “Cable” is selected this function may not be available in some countries.
“Auto DST”: Sets whether or not to automatically switch between summer time and
winter time.
• “On”: Automatically switches between summer time and winter time according to the
calendar.
• “Off”: The time is displayed according to the time difference set by “Time Zone”.
~
• When "Cable" is selected this function may not be available in some countries.
“Service Replacement”: Select “On” to automatically change the channel when
broadcaster changes transmission of the viewing programme to a different channel.
CA Module Set-up
Allows you to access a pay TV service once you obtain a Conditional Access Module (CAM)
and a view card. See page 17 for the location of the (PCMCIA) socket.
