27
GB
Using MENU Functions
Digital Set-up
Digital Tuning
Digital Auto Tuning
Tunes in the available digital channels.
This option allows you to retune the TV after moving house, or to search for new
channels that have been launched by broadcasters. Press .
Programme List Edit
Removes any unwanted digital channels stored on the TV, and changes the order of
the digital channels stored on the TV.
1 Press
F/f to select the channel you want to remove or move to a new
position.
Press the number buttons to enter the known three-digit programme number of the
broadcast you want.
2 Remove or change the order of the digital channels as follows:
To remove the digital channel
Press . After a confirmation message appears, press
G
to select “Yes”, then press .
To change the order of the digital channels
Press g, then press F/f to select the new position for the channel and press G.
3 Press RETURN.
~
• When “Cable” is selected this function may not be available in some countries.
Digital Manual Tuning
Tunes the digital channels manually.
1 Press the number button to select the channel number you want to
manually tune, then press
F/f to tune the channel.
2 When the available channels are found, press
to store programmes.
Repeat the above procedure to manually tune other channels.
~
• Not available for Cable connection.
Digital Set-up
Subtitle Set-up
“Subtitle Setting”: When “For Hard Of Hearing” is selected, some visual aids may
also be displayed with the subtitles (if TV channels broadcast such information).
“Primary Preferred Language”: Selects preferred language which subtitles are
displayed in.
“Secondary Preferred Language”: Selects secondary preferred language which
subtitles are displayed in.
Audio Set-up
“Audio Type”: Switches to broadcast for the hearing impaired when “For Hard Of
Hearing” is selected.
“Primary Preferred Language”: Selects the preferred language used for a programme.
Some digital channels may broadcast several audio languages for a programme.
“Secondary Preferred Language”: Selects the secondary preferred language used
for a programme. Some digital channels may broadcast several audio languages for
a programme.
“Audio Description”: Provides audio description (narration) of visual information
if TV channels broadcast such information.
“Mixing Level”: Adjusts the TV main audio and Audio Description output levels.
z
• This option is only available when “Audio Description” is set to “On”.
“Dynamic Range”: Compensates for differences in the audio level between
different channels (only for Dolby Digital audio).
Continued
